English (Original instructions)
EN
DE ES IT FR PT NL RU FI SV NO DA PL CS SK SL HR HU RO BG EL AR TR HE LT LV ET
SPECIFICATIONS
Model 2203407
Voltage 60V
No load speed 3400 (±10%) min
-1
Blade speed 3400 (±10%) min
-1
Blade length 61 cm
Cutting capacity 27 mm
Measuered sound pressure
level
80 dB (A), k=3.0
Guaranteed sound power
level
94 dB (A)
Vibration level <2.5 m/s², k=1.5 m/s²
Weight without battery pack 4.5 kg
DESCRIPTION
See figure 1.
1. Blade cover
2. Blade
3. Guard
4. Front handle
5. Micro switch
6. Lock-out button
7. Trigger switch
8. Rotate release
9. Rear handle
10. Battery
11. Battery release button
ASSEMBLY
UNPACKING
This product requires no assembly.
Carefully remove the product and any accessories
from the box. Make sure that all items listed in the
packing list are included.
Inspect the product carefully to make sure no
breakage or damage occurred during shipping.
Do not discard the packing material until you have
carefully inspected and satisfactorily operated the
product.
PACKING LIST
Hedge trimmer
Operator's manual
OPERATION
For complete charging instructions, refer to the
Operator’s Manuals for your battery pack and charger
models.
NOTE: To avoid serious personal injury, always remove
the battery pack and keep hands clear of the lock-out
button when carrying or transporting the tool.
INSTALL BATTERY PACK
Place the battery pack in the hedge trimmer. Align
groove in battery pack with raised rib on hedge
trimmer. See figure 2.
Make sure the latch on the hedge trimmer snaps
in place and that battery pack is secured in hedge
trimmer before beginning operation.
REMOVE BATTERY PACK
Locate the latch on the hedge trimmer and depress
to release the battery pack from the hedge trimmer.
See Figure 2.
Remove battery pack from the hedge trimmer.
CAUTION
When placing battery pack in your hedge trimmer,
be sure groove in battery pack aligns with raised rib
on hedge trimmer and latch snaps in place properly.
Improper assembly of battery pack can cause
damage to internal components.
STARTING THE HEDGE TRIMMER
See figure 3.
Remove the blade cover.
Install the battery pack.
For added safety, there is a micro switch (5) in
the front handle. When operating, hold the hedge
trimmer with both hands, one hand to press the
lock-out button (6) and squeeze the trigger switch
(7), and the other hand to squeeze the micro switch
(5).
Release the lock-out button (6) and continue to
squeeze the trigger switch (7) and micro switch (5)
for extended operation.
STOPPING THE HEDGE TRIMMER
See figure 3.
Release the micro switch (5) and trigger switch (7)
to stop the hedge trimmer.
Upon release of the trigger switch (7), the lock-out
button (6) will be automatically reset to the lock
1
