11
ORIGINAL INSTRUCTIONS
EN
TOOL CHARACTERISTICS
Pneumatic grinder is a tool supplied with compressed air at proper pressure. Using cutting or grinding discs it is possible to cut and grind various
materials. The tool is adapted to work indoors and should not be exposed to humidity and atmospheric precipitations. The tool is not designed for
continuous operation. The recommended operating mode is short-time duty in a period of 5 minutes, than it is required to wait 30 minutes in order
to cool down the tool. Correct, reliable and safe operation of the tool depends on proper operation, therefore:
Before starting the work with this tool, please read this manual and keep it properly.
The supplier does not assume any liability for any damages resulting from misuse of the tool, failure to follow safety regulations and recommendations
specifi ed in this manual. Misuse of the product will also result in loss of guarantee rights of the user and also due to a breach of an agreement.
EQUIPMENT
The grinder is fi tted with a coupling that allows connecting it to pneumatic system. Accessories also include spanners that allow affi xing additional
accessories in tool chuck.
TECHNICAL DATA
Parameter Measuring unit Value
Catalogue number YT-09632
Weight [kg] 0.45
Air connector diameter (PT) [mm / ”] 6.3 / 1/4
Air hose diameter (internal) [mm / ”] 10 / 3/8
Rotation [min
-1
] 25 000
Tool chuck diameter [mm] 6
Maximum working pressure [MPa] 0.63
Required air fl ow (at 6.2 bar) [l/min] 113
Acoustic pressure (ISP 15744) [dB(A)] 88,0 ± 3,0
Acoustic power (ISP 15744) [dB(A)]
99,0 ± 3,0
Oscillations(ISO 28927-12) [m/s
2
] 2,9 ± 1,5
GENERAL SAFETY CONDITIONS
WARNING! When working with pneumatic tool it is always recommended to follow basic rules of safety at work, including those mentioned below,
in order to limit the risk of fi re, electric shock and avoid injuries.
Before starting the work with this tool, please read this manual and keep it properly.
NOTE! Read all instructions below. Failure to observe them may lead to electric shock, fi re or body injuries. The term “pneumatic tool” used in
instructions refers to all tools supplied with a jet of compressed air at right pressure.
ADHERE TO INSTRUCTIONS BELOW
General safety rules
Prior to installation, work, repair, maintenance and replacement of accessories or in the event of work close to pneumatic tool, due to many threats,
please read and understand these safety instructions. Failure to perform the above duties may result in severe body injuries. Installation, adjustment
and assembly of pneumatic tools may be carried out only by qualifi ed and trained personnel. Do not modify a pneumatic tool. Modifi cation may
lower the effi ciency and level of safety and increase the risk of tool operator. Do not throw away the safety instruction, it should be transferred to a
tool operator. Do not operate pneumatic tool if it is damaged. A tool should undergo periodic inspection for visibility of data required by ISO 11148
