– 2

1 Pickup for floor nozzle

2 Suction hose

3 Air outlet, working air

4 Suction head

5 Suction head lock

6 Dirt receptacle

7 Steering roller

8 Recessed grip

9 Air inlet, motor cooling air

10 Suction support

11 Socket (Ap Te L only)

12 Floor nozzle

13 Suction tube

14 Main switch

15 Button for filter shake off system

16 Carrying handle

17 Fixing eyelet

18 Hose hook

19 Float

20 Bender

21 Cartridge filter (PES)

22 Fastening nut

23 Holder for suction pipe

24 Power cord

25 Nameplate

26 Cable hook

 DANGER

– When the outgoing air is carried back

into the room, a sufficient ventilation

rate L in the room must be ensured. To

comply with the required limit values the

carried back volume flow must be 50%

of the fresh air volume flow (room vol-

ume V

R

x ventilation rate L

W

) at maxi-

mum. Without a specific ventilation sys-

tem the following applies: L

W

=1h

–1

.

– Only persons trained in the use of the

machine and the handling of substanc-

es for which the machine is to be used

including training in the safe disposal of

the sucked-in material may use the ma-

chine.

– This appliance contains harmful dust.

Evacuation and maintenance work, in-

cluding the disposal of the dust collec-

tion containers, may only be performed

by specialists who wear the appropriate

protective equipment.

– Do not use the appliance without the

complete filtering system.

– Please follow the safety regulations ap-

plicable to the materials that are to be

treated.

몇 WARNING

For vacuuming, the cartridge filter must al-

ways be installed.

몇 WARNING

Do not vacuum without the filter elements;

otherwise, the suction motor can get dam-

aged and this can be hazardous to health

on account of increased release of fine dust

particles.

– The device is equipped with a fleece fil-

ter bag with a lock latch, order no.

2.889-217.0 (5 units).

Note: You can use this appliance to vacu-

um all types of dust up to dust class L.

Device elements

Symbols on the machine

WARNING: This appliance contains harm-

ful dust. The emptying and maintenance,

including the removal of the dust bag, may

only be executed by trained personnel

wearing suitable protection equipment. Do

not switch on until the complete filter sys-

tem has been installed.

Cartridge filter (PES)

Order No. 2.889-219.0

Safety instructions

Start up

Dry vacuum cleaning

13EN
