3
ENGLISH
HYDRAULIC PULLER TYPE PUNCHING TOOL
TYPE HT-FL75
CAUTION
• Before each use, check the punches, dies and draw studs, and replace any that are worn or
damaged, particulary any punches that have damaged cutting surfaces.
• Damaged or improperly assembled accessories can break and hit the operator with sufficient
force to cause serious injuries.
• Before each use, verify the integrity of the head; replace any worn, possibly damaged or missing
parts with original Cembre spares.
• Only for use in punching holes in single layers of material and thicknesses as shown in TABLES
1 and 2. Any other use may cause components to break with potential risk of serious injury.
• During operation do not allow anyone to pause in the work area, especially in front of the
punch.
• The use of Cembre punching accessories is recommended. Accessories from other suppliers
may not be designed to withstand the force generated by this tool and may be damaged or
break with potential risk of serious injury.
1. GENERAL CHARACTERISTICS
– Application range: suitable for punching single layers of stainless steel, mild steel, fibreglass and
plastic material.
– Max. puncing capacity: ........................................................................................... ø 140 mm (5.5 in.)
– Developed force: ....................................................................................................... 75 kN (8.4 sh.ton.)
– Max. operating pressure ........................................................................................ 700 bar (10,000 psi)
– Dimensions: length .................................................................................................. 452 mm (17.8 in.)
width .................................................................................................... 129 mm (5.1 in.)
– Weight: ........................................................................................................................... 3,67 kg (8.1 lbs)
– Oil: ........................................................................................... AGIP ARNICA 32 or
SHELL TELLUS OIL TX 32 or equivalent
The part code “HT-FL75” includes the following:
– Hydraulic tool.
– ø 11.5 mm Spiral bit (code 6134070).
– TD-11 Draw stud with threaded 7/16"-3/4" (code 2685005).
– TD-19 Draw stud with threaded 3/4"-3/4" (code 2685008).
– Plastic carrying case type VAL P28.
2. INSTRUCTIONS FOR USE
2.1) Setting
Consult the tables on pages 26 and 27 and select the RD... Punching Kit suitable for the hole to be
made. For punching requirements other than those listed, please contact Cembre.
