10

Список деталей: рычажная таль

JLPА/B № № детали обозначение

размер кол-во

1 ......... JLP50-1 ............... Cover ..................................................... ................................ 1

5 ......... JLP50-5 ............... Cover Side Plate Assembly (serial #6253 and lower) ...................... 1

........... .......................... Cover Side Plate ...................................... ................................ 1

........... .......................... Stay Bolt ................................................ ................................ 3

........... .......................... Race ...................................................... ................................ 1

........... .......................... Guide Plate ............................................. ................................ 1

........... .......................... Rivet ...................................................... 4x10 ......................... 2

........... JLP50-5A ............. Cover Side Plate Assembly (serial #8100 and higher) ..................... 1

........... .......................... Cover Side Plate ...................................... ................................ 1

........... .......................... Stay Bolt ................................................ ................................ 3

........... .......................... Race ...................................................... ................................ 1

7 ......... JLP50-7 ............... Load Shaft .............................................. ................................ 1

9 ......... JLP50-9 ............... Guide Roller (serial #6253 and lower) ......... ................................ 2

........... JLP50-9A ............. Guide Block (serial #8001 and higher) ........ ................................ 2

10 ....... JLP50-10 .............. Stripper (serial #6253 and lower) ............... ................................ 1

........... JLP50-10A ............ Stripper (serial #8001 and higher) ............. ................................ 1

13 ....... JLP75-13 .............. Pawl Spring (1/2, 3/4T) ............................ ................................ 2

14 ....... JLP50-14 .............. Pawl ....................................................... ................................ 2

15 ....... JLP75-15 .............. Snap Ring (1/2, 3/4T) ............................... 8 .............................. 2

16 ....... JLP50-16 .............. Lever Side Plate Assembly (serial #6253 and lower) ...................... 1

........... .......................... Lever Side Plate ....................................... ................................ 1

........... .......................... Race ...................................................... ................................ 1

........... .......................... Pawl Pin ................................................. ................................ 2

........... JLP50-16A ............ Lever Side Plate Assembly (serial #8001 and higher) ..................... 1

........... .......................... Lever Side Plate ....................................... ................................ 1

........... .......................... Race ...................................................... ................................ 1

........... .......................... Pawl Pin ................................................. ................................ 2

17 ....... JLP50-17 .............. Disc Hub ................................................. ................................ 1

18 ....... JLP75-18 .............. Spring (1/2, 3/4, 1-1/2T) .......................... ................................ 1

19 ....... JLP50-19 .............. Friction Disc ............................................ ................................ 2

20 ....... JLP50-20 .............. Ratchet Disc ............................................ ................................ 1

22 ....... JLP50-22 .............. Brake Cover Assembly .............................. ................................ 1

........... .......................... Brake Cover ............................................ ................................ 1

........... .......................... Handle Case ............................................ ................................ 1

........... .......................... Nut ........................................................ .........................

....... 2

........... .......................... Bushing .................................................. ................................ 1

23 ....... JLP50-23 .............. Change Over Gear .................................... ................................ 1

24 ....... JLP75-24 .............. Lever Handle Assembly (1/2, 3/4T) ............ ................................ 1

........... .......................... Lever Handle ........................................... ................................ 1

........... .......................... Selector Lever ......................................... ................................ 1

........... .......................... Change Over Shaft ................................... ................................ 1

........... .......................... Cover ..................................................... ................................ 1

........... .......................... Rivet ...................................................... 3x16 ......................... 1

........... .......................... Bolt ........................................................ ................................ 2

........... .......................... Spring Seat ............................................. ................................ 1

........... .......................... Bushing .................................................. ................................ 1

24A ..... JLP75-24A ............ Rubber Grip ............................................ ................................ 1

25 ....... JLP75-25 .............. Change Over Pawl (1/2, 3/4T) ................... ................................ 1

26 ....... JLP75-26 .............. Spring Shaft (1/2, 3/4T) ........................... ................................ 1

27 ....... JLP75-27 .............. Spring (1/2, 3/4T) .................................... ................................ 1

28 ....... JLP75-28 .............. Hand Wheel (1/2, 3/4T) ............................ ................................ 1

29 ....... JLP50-29 .............. Name Plate ............................................. ................................ 1

30 ....... JLP75-30 .............. Chain Stop .............................................. ................................ 1

31 ....... JLP75-31 .............. Hex Nut(1/2, 3/4T) .................................. M8 ............................ 6

32 ....... JLP75-32 .............. Lock Washer (1/2, 3/4T) ........................... M8 ............................ 6

32A ..... JLP75-32A ............ Flat Washer (1/2, 3/4T) ............................ M8 ............................ 6

33 ....... JLP75-33 .............. Hex Nut (1/2, 3/4T) ................................. M6 ............................ 2
