HSE 61, HSE 71, HSE 81
English
36
Engine
HSE 61
HSE 71
HSE 81
Cutting Blades
HSE 61
HSE 71
HSE 81
Weight
HSE 61
HSE 71
HSE 81
Noise and Vibration Data
Noise and vibration data are determined
on the basis of the rated maximum
speed.
For further details on compliance with
Vibration Directive 2002/44/EC see
www.stihl.com/vib/
Sound pressure level L
p
to
EN 60745-2-15
Sound power level L
w
to EN 60745-2-15
Specifications
Voltage: 230 - 240 V
Rated current: 2.1 A
Frequency: 50 Hz
Power consumption: 500 W
Fuse: min. 10 A
Insulation: II, E
Voltage: 230 - 240 V
Rated current: 2.6 A
Frequency: 50 Hz
Power consumption: 600 W
Fuse: min. 10 A
Insulation: II, E
Voltage: 230 - 240 V
Rated current: 2.8 A
Frequency: 50 Hz
Power consumption: 650 W
Fuse: min. 10 A
Insulation: II, E
Sharpening angle: 34°
Tooth spacing: 29 mm
Stroke rate: 3,200/min
Cutting length: 500 mm, 600 mm
Sharpening angle: 28°
Tooth spacing: 36 mm
Stroke rate: 2,600/min
Cutting length: 600 mm, 700 mm
Sharpening angle: 45°
Tooth spacing: 36 mm
Stroke rate: 2,600/min
Cutting length: 500 mm, 600 mm,
700 mm
500 mm blade: 3.9 kg
500 mm blade
1)
:4.6kg
600 mm blade: 4.1 kg
600 mm blade: 4.1 kg
500 mm blade
1)
:4.8kg
700 mm blade: 4.2 kg
700 mm blade
1)
:4.9kg
500 mm blade: 4.1 kg
600 mm blade: 4.2 kg
700 mm blade: 4.4 kg
700 mm blade
1)
:5.0kg
1)
Version with 10 meter power supply
cord for UK
HSE 61
500 mm blade: 85 dB(A)
600 mm blade: 85 dB(A)
HSE 71
600 mm blade: 88 dB(A)
700 mm blade: 88 dB(A)
HSE 81
500 mm blade: 88 dB(A)
600 mm blade: 88 dB(A)
700 mm blade: 88 dB(A)
HSE 61
500 mm blade: 96 dB(A)
600 mm blade: 96 dB(A)
