Assembly

467 773_a 13

3. If the water carries a small amount of sand

you must fit a pre-filter between the suction

line and the pump inlet. Ask your expert dea-

ler about this.

4. Always lay the suction line with an upwards

gradient.

ADVICE

If the suction height is more than 4m, you

must use a suction hose having a diame-

ter greater than 1". We recommend the

use of an AL-KO suction unit with suction

hose, suction filter and flow-back stop.

Ask your expert dealer.

Mounting the pressure line

1. Screw the connecting nipple (Fig. B -13) with

the round seal ring (Fig. B -14) into the pump

outlet (Fig. A -3).

2. Screw the elbow nipple (Fig. B -11) with seal

ring (Fig. B -12) onto the connecting nipple

(Fig. B -13) and turn the elbow nipple in the

desired direction.

3. Fix a pressure line (Fig. B -10) to the elbow

nipple (Fig. B -11).

4. Open all closing off devices (valves, spray

nozzles, water cock) in the pressure line.

STARTUP

Filling the garden pump

CAUTION!

Dry running will destroy the pump! The

pump must be filled with water up to the

overflow before each use so that it can

draw water immediately.

1. Open the filling screw (Fig. B -8).

2. Fill with water via the filling screw until the

marl on the pump housing is reached.

3. Screw the filling screw back in position.

Switch the pump on

1. Open all closing off devices (valve, spray

nozzle, water cock) in the pressure line.

2. Insert the mains plug on the connection cable

into the plug socket.

3. Switch the garden pump on at the on / off

switch.

CAUTION!

Do not allow the pump to run against a

closed off pressure line.

Switch pump off

1. Switch the garden pump off at the on / off

switch after use.

2. Close all the closing off devices in the pres-

sure line.

ADVICE

If nothing is drawn up for longer than

180 seconds, the garden pump automa-

tically switches to "Fault" and turns off.

CAUTION!

Danger of injury from hot water

In extended use against the closed pres-

sure side (>10 min.), the water in the

pump can be severely heated up and can

be emitted in an uncontrolled manner!

Isolate the unit from the mains and allow

the pump and water to cool down. Start

the unit again only after all the faults have

been rectified!

The risk of injury from hot water can arise if:

the installation is not correct

the pressure side is closed off

there is a lack of water in the suction line, or if

the pressure switch is defective.

Procedure

1. Isolate the unit from the mains and allow the

pump and water to cool down.

2. Check the unit, the installation and water le-

vel.

3. Start the unit again only after all the faults

have been rectified!

MAINTENANCE AND CARE

CAUTION!

The pump must be isolated from the

mains before any maintenance and ser-

vice work. Remove the mains plug from

the plug socket.

Flushing the pump

After conveying swimming pool water containing

chlorine or fluids that leave a residue the pump

must be flushed out with clear water.

Remove blockages

1. Isolate the unit from the mains and secure

against switching on again.

2. Remove the suction hose from pump inlet.
