English

WARNING

Always shut off engine and allow it to cool for 5 minutes

before refuelling. Never remove the cap of the fuel tank

or add petrol to a machine with a running or hot engine.

Move at least 9 m (30 ft) from refuelling site before

starting the engine. Do not smoke. Failure to heed this

warning could result in serious personal injury.

WARNING

Do not overﬁ ll. Fill the fuel tank to 25 mm below the top

of the fuel neck. After fueling, never tilt the mower more

than 25 degrees for this could result in fuel leakage and

risk of ﬁ re, etc.

1. Clean surface around the fuel cap to prevent

contamination.

2. Slowly loosen the fuel cap to release pressure and to

keep fuel from escaping around the cap. Rest the cap

on a clean surface.

3. Carefully pour petrol into the tank. Avoid spillage.

4. Clean and inspect the gasket. Replace and secure all

fuel and container caps.

5. Wipe up any fuel spillage. Move 9 m away from the

refuelling site before starting the engine.

NOTE: It is normal for smoke to be emitted from a new

engine during and after ﬁ rst use.

ADDING/CHECKING ENGINE OIL

See figure 5.

Engine oil has a major inﬂ uence on engine performance

and service life. For general, all-temperature use, SAE

10W-30 is recommended. Always use a 4-cycle motor oil

that meets or exceeds the requirements for API service

classiﬁ cation SJ.

NOTE: Non-detergent or 2-cycle engine oils will damage

the engine and should not be used.

To add engine oil:

1. Be sure the mower is level and the area around the oil

cap/dipstick is clean.

2. Remove the cap and the seal from the oil bottle.

3. Open the oil cap/dipstick by turning it 90°

counterclockwise. Remove the oil cap/dipstick.

4. Slowly add oil. Fill to the “Full” line on the dipstick. Do

not overﬁ ll.

NOTE: When checking the oil level, seat the dipstick in the

oil ﬁ ll hole but do not screw in.

5. Reinstall and secure the oil cap/dipstick by turning it 90°

clockwise.

To check engine oil:

■ Be sure mower is level and area around oil cap/dipstick

is clean.

■ Remove the oil cap/dipstick. Wipe clean and reseat in

the oil ﬁ ll hole but do not screw in.

■ Remove the oil cap/dipstick again and check the oil

level. Add oil as needed.

STARTING OR STOPPING THE MOWER

See figure 5.

WARNING

Never start or run the engine inside a closed or poorly

ventilated area; breathing exhaust fumes can kill.

Starting the engine

1. Press the primer bulb 3 times.

NOTE: This step is not usually necessary when starting

an engine that has already run for a few minutes.

2. Hold the power lever bar down against the handle.

3. Pull the starter grip until the engine starts. Slowly

release the starter cord so that the rope does not snap

back.

NOTE: It may be necessary to repeat the priming steps

in cooler weather. In warmer weather, overpriming may

cause flooding and the engine will not start. If you do

flood the engine, wait a few minutes before attempting

to start and do not repeat priming steps.

Stopping the engine

■ Release the power lever and allow the engine to come

to a complete stop.

PROPELLING THE PRODUCT

See figure 6.

■ To self-propel: Hold down the power lever while slowly

pulling the self-propel bail towards the handle. Release

the self-propel bail to stop the wheel drive.

■ To manually propel: Hold down the power lever. Do not

engage the self-propel bail.

NOTE: The product will start to run when the self-

propel bail is engaged.

SETTING BLADE HEIGHT

See figure 7.

When shipped, the wheels on the mower are set to a low-

cutting position. Before using the mower for the ﬁ rst time,

adjust the cutting position to the height best suited for your

lawn. The average lawn should be between 38 mm to 50

mm during cool months and between 50 mm and 76 mm

during hot months.

To set the blade height:

■ Stop the product and wait for the blade to come to a

complete stop.

■ To raise the blade height, grasp the height adjustment

lever and move it toward the back of the mower.

■ To lower the blade height, grasp the height adjustment

lever and move it toward the front of the mower.
