Hour meters - TBW series

TBW70.29

DIN-Rail mounting

Width 35mm

Without zero reset

Without terminal cover

12.02– 4

1. Indicators

Counter capacity: 99 999h

Accuracy of reading: 0.1h

Numeral colour: white, decimal figures red

Numeral height: 4.4mm

Operation indicator: flashing LED

2. Mechanical design

Self-extinguishing plastic housing, IP rating IP50

Class of protection II

Mounted on DIN-Rail TS 35 according to EN 50022

Shockproof terminal connection according to VBG 4,

IP rating IP20

Initial torque: max. 4Nm

Terminal capacity:

1 x 1.5 to 10mm

without multicore cable end

2 x 0.8 to 2.5mm

without multicore cable end

1 x 1.0 to 6mm

flexible with multicore cable end

2 x 0.8 to 2.5mm

flexible with multicore cable end

3. Input circuit

Supply voltage:

24V AC (TBW70.29 24VAC)

230V AC (TBW70.29 230VAC)

Tolerance:

24V AC ±15% (TBW70.29 24VAC)

230V AC ±15% (TBW70.29 230VAC)

Rated frequency: 50 to 60Hz

Rated consumption:

24V AC approx. 0.1VA (TBW70.29 24VAC)

230V AC approx. 1.5VA (TBW70.29 230VAC)

4. Ambient conditions

Ambient temperature: -15 to +55°C

Storage temperature: -15 to +55°C

Transport temperature: -15 to +55°C

Relative humidity: <90%

5. Accessories

KA-TBX70.29: sealable terminal cover

Technical data

Subject to alterations and errors

Release 11/01
