442947_a 17
Product description
CAUTION! Denotes a potentially dangerous
situation which can result in minor or moderate
injury if not avoided.
IMPORTANT! Denotes a situation which can
result in material damage if not avoided.
NOTE Special instructions for ease of un-
derstanding and handling.
2 PRODUCT DESCRIPTION
2.1 Designated use
This appliance is intended for mowing a lawn in
non-commercial applications. Any other use, in-
cluding unauthorised conversions or add-ons, are
regarded as contrary to the intended use and will
result in the warranty becoming void; this means
the manufacturer will reject any responsibility for
damage and/or injury suffered by the user or third
parties.
2.2 Possible foreseeable misuse
The tool is designed neither for commercial use
in public parks and sports facilities, nor for use in
farming and forestry.
2.3 Residual risks
Even during correct use of the appliance, there is
always a certain residual risk that cannot be ex-
cluded. Depending on the use, the following po-
tential risks can be derived from the type and
construction of the appliance:
■
Throwing out of cuttings, soil and small
stones.
■
Inhalation of cuttings particles if no breathing
protection is worn.
■
Lacerations from reaching into the rotating
cutting blade.
2.4 Product overview
2.4.1 Product overview – easy and comfort
(01)
The product overview gives an overview of the
two products, RazorCut 28.1 HM easy and Ra-
zorCut 38.1 HM comfort.
No. Component
1 Handlebar – upper brace
2 Handlebar – intermediate brace *
3 Handlebar – lower brace
4 Wing bolts **
No. Component
5 Discharge extension ***
6 Spindle with blades
7 Counterblade
8 Roller
9 Pull knob for height adjustment
*: On RazorCut 28.1 HM easy only
**: On RazorCut 38.1 HM comfort only
***: Option, together with grass collector (not included in scope
of supply).
2.4.2 Product overview – premium (12)
The product overview provides an overview of
the RazorCut 38.1 HM premium.
No. Component
1 Handlebar – upper brace, with han-
dlebar padding
2 Handlebar – intermediate brace
3 Handlebar – lower brace
4 Wing bolts
5 Discharge extension, integrated
6 Spindle with blades
7 Counterblade
8 Roller
9 Handles for height adjustment
10 Lock nuts for height adjustment
2.5 Scope of supply
The items listed here are included as standard.
Check that all items are present.
2.5.1 Scope of supply – easy and comfort
(02)
No. Component
1 Upper brace * |**
2 Intermediate brace *
3 Lower brace * |**
4 Cylinder mower * |**
5 Studs with square head (4x) *
Studs with square head and washers
(2x) **
