Model No.DUN461W 460MM DC POLE HEDGE TRIMMER

Item Parts No. Description I/C Qty New/Old Opt. 1 Opt. 2 Note

001 183S96-1 GRIP HOUSING SET 1

󳢢󳢢󳢢󳢢C10 263005-3 RUBBER PIN 6 2

󳢢󳢢󳢢󳢢D10 INC. 12

002 811M68-7 DUN461W SERIAL NO. LABEL 1

003 643874-2 TERMINAL 1

004 620F42-0 CONTROLLER 1

005 651398-4 SWITCH BMC-1112-001 1

006 231473-8 COMPRESSION SPRING 4 1

007 231473-8 COMPRESSION SPRING 4 1

008 413714-6 SWITCH LEVER 1

009 413713-8 LOCK OFF BUTTON A 1

010 699168-3 POWER SUPPLY CORD UNIT 1

󳢢󳢢󳢢󳢢C10 654069-2 RECEPTACLE 2

011 327810-3 BATTERY GUARD 1

012 183S96-1 GRIP HOUSING SET 1

󳢢󳢢󳢢󳢢C10 263005-3 RUBBER PIN 6 2

󳢢󳢢󳢢󳢢D10 INC. 1

013 811M62-9 DUN461W NAME PLATE 1

014 266326-2 TAPPING SCREW 4X18 6

016 921362-2 HEX. BOLT M6X40 1

017 264072-1 THUMB NUT M6 1

󳢢󳢢󳢢󳢢C10 931302-2 HEX. NUT M6 1

018 413712-0 PIPE CAP 32 1

019 141B61-4 PIPE 32 COMPLETE 1 *

󳢢󳢢󳢢󳢢C10 8008A7-9 CAUTION LABEL 1 *

󳢢󳢢󳢢󳢢C20 808723-2 CAUTION LABEL 1 *

020 413719-6 FRONT GRIP A 1

021 141C39-3 PIPE HOLDER 32 COMPLETE 1

󳢢󳢢󳢢󳢢C10 252103-8 HEX. LOCK NUT M5-8 1

022 911243-8 PAN HEAD SCREW M5X25 1

023 413711-2 PIPE CAP 28 1

024 327815-3 PIPE 28 1 *

025 251568-1 H.S.H.BOLT M3X12 WITH WR 1

029 213616-4 O RING 48 1

030 183T14-5 PIPE HOLDER SET 1

󳢢󳢢󳢢󳢢D10 INC. 32

031 266326-2 TAPPING SCREW 4X18 4

032 183T14-5 PIPE HOLDER SET 1

󳢢󳢢󳢢󳢢D10 INC. 30

033 213616-4 O RING 48 1

034 231113-8 COMPRESSION SPRING 12 1

035 413715-4 LOCK OFF BUTTON B 1

Please order the parts with part number. Print Date 10/12/2021
