ENGLISH

Installing Diamond Blades (Fig. A, C,D)



WARNING: To reduce the risk of serious personal

injury, turn tool off and disconnect battery pack

before making any adjustments or removing/

installing attachments or accessories. An accidental

start-up can causeinjury.



WARNING: Burn Hazard. Sharp parts. ALWAYS wear

gloves when changing diamond blades. Diamond

blades have sharp edges or may get extremely hot during

operation, and may damage barehands.



WARNING: Never install more than two diamondblades.



WARNING: All spacers need to beinstalled.Lay unit on a

firm surface, with the spindle

20

facingupward.

1. Unlatch the guard locking lever

13

and open the

guard

12

2. Install the unthreaded backing flange

7

on spindle

20

with

the raised centre (pilot) facing upward.

Inserting and Removing the Battery Pack

from the Tool (Fig. B)

NOTE: Make sure your battery pack

9

is fullycharged.

To Install the Battery Pack into the Tool Handle

1. Align the battery pack

9

with the rails inside the tool’s

handle (Fig. B).

2. Slide it into the handle until the battery pack is firmly seated

in the tool and ensure that you hear the lock snap intoplace.

To Remove the Battery Pack from the Tool

1. Press the release button

10

and firmly pull the battery pack

out of the toolhandle.

2. Insert battery pack into the charger as described in the

charger section of thismanual.

Fuel Gauge Battery Packs (Fig. B)

Some

DeWALT

battery packs include a fuel gauge which

consists of three green LED lights that indicate the level of

charge remaining in the batterypack.

To actuate the fuel gauge, press and hold the fuel gauge

button

19

. A combination of the three green LED lights will

illuminate designating the level of charge left. When the level

of charge in the battery is below the usable limit, the fuel gauge

will not illuminate and the battery will need to berecharged.

NOTE: The fuel gauge is only an indication of the charge left on

the battery pack. It does not indicate tool functionality and is

subject to variation based on product components, temperature

and end-userapplication.

Electronic Clutch

The electronic torque limiting clutch reduces the maximum

torque reaction transmitted to the operator in case of jamming

of a diamond blade. This feature also prevents the gearing and

electric motor from stalling. The torque limiting clutch has been

factory–set and cannot beadjusted.

Brake

Once the power is shut off, the brake stops the diamond blades

spinning more quickly than a unit without this feature. This

improves efficiency and increases user protection. Stopping

time will vary depending upon the type of wheelused.

DeWALT

Bluetooth® Tool Tag Ready (Fig.C)

Optional Accessory



WARNING: Read instruction manual for the

DeWALT

Bluetooth® ToolTag.



WARNING: Turn tool off and disconnect battery pack

before installing the

DeWALT

Bluetooth® ToolTag.



WARNING: When installing or replacing the

DeWALT

Bluetooth® Tool Tag, use only the screws provided. Be sure

to securely tighten thescrews.

Your tool comes with mounting holes

16

for installing a

DeWALT

Bluetooth® Tool Tag (DCE041). Use only the original

fasteners included with the tool tag. You will need a T15 (Torx)

bit tip to install the tag. The

DeWALT

Tool Tag is designed for

tracking and locating professional power tools, equipment, and

machines using the

DeWALT

Tool Connect™ app. For proper

installation of the

DeWALT

Tool Tag refer to the

DeWALT

Tool

Tagmanual.

Depth Adjustment Dial (Fig.A)

To adjust the cutting depth, push in on the depth adjustment

dial

11

and rotate to the desired depth. Ensure the depth

adjustment is set to the required depth of thechannel.

Always return the tool to the "Park" position (P) afteruse.

DO NOT use under wet conditions or in the presence of

flammable liquids orgases.

This wall chaser is a professional powertool.

DO NOT let children come into contact with the tool.

Supervision is required when inexperienced operators use

thistool.

• Young children and the infirm. This appliance is not

intended for use by young children or infirm persons

without supervision.

• This product is not intended for use by persons (including

children) suffering from diminished physical, sensory or

mental abilities; lack of experience, knowledge or skills

unless they are supervised by a person responsible for their

safety. Children should never be left alone with thisproduct.

ASSEMBLY AND ADJUSTMENTS



WARNING: To reduce the risk of serious personal

injury, turn tool off and disconnect battery pack

before making any adjustments or removing/

installing attachments or accessories. An accidental

start-up can causeinjury.



WARNING: Use only

DeWALT

battery packs andchargers.
