• After switching o allow the cutting blade to stop completely, only

then you can put the wall chaser away.

• The chase is fully emptied and does not require chiselling.

After switching the wall chaser o, do not brake the rotating blade by

pressing it against processed material.

Do not apply excessive pressure on the wall chaser, do not push it

forward forcefully. Pressure while plunging and moving should be

moderate. Applying excessive pressure may cause motor overheating

and damage of the cutting blade.

Cutting blades heat up to high temperatures during operation – do

not touch them with unprotected parts of your body before they cool

down.

When cutting very hard materials, cutting blade may be overheated

and damaged in consequence. Shower of sparks around the cutting

blade indicates overheating. When it appears, immediately stop

cutting and cool down the blade by running it with full rotational

speed with no load for 3–5 minutes.

Noticeable decrease of cutting eciency and shower of sparks

around the cutting blade may indicate blunt cutting blade.

Use only working tools whose allowable rotary speed is higher or

equal to maximum wall chaser speed with no load.

OPERATION AND MAINTENANCE

Unplug the power cord from mains socket before commencing any

activities related to installation, adjustment, repair or maintenance.

MAINTENANCE AND STORAGE

• Cleaning the device after each use is recommended.

• Do not use water or any other liquid for cleaning.

• Clean the tool with a dry cloth or blow with compressed air at low

pressure.

• Do not use any cleaning agents or solvents, they may damage plastic

parts.

• Clean ventilation holes in the motor casing regularly to prevent

device overheating.

• In case of power cord damage replace it with a cord with the same

specication. Entrust the repair to a qualied specialist or return the

tool to a service point.

• In case of excessive commutator sparking, have the technical

condition of carbon brushes of the motor checked by a qualied

person.

• Always store the tool in a dry place, beyond reach of children.

REPLACEMENT OF CARBON BRUSHES

Immediately replace worn out (shorter than 5 mm), burnt or cracked

motor carbon brushes. Always replace both carbon brushes at a time.

• Unscrew and remove carbon brush covers (8).

• Pull the pressure spring away, snap out and remove worn out carbon

brushes.

• Remove any carbon dust with compressed air.

• Install new carbon brushes (they should easily slide into the brush

holders) and reinstall the pressure spring.

• Fix carbon brush covers (8).

After replacement of carbon brushes, start the power tool with no

load and wait 1–2 minutes until the carbon brushes t to the motor

commutator. Entrust replacement of carbon brushes only to a

qualied person. Only original parts should be used.

All defects should be repaired by service workshop authorized by the

manufacturer.

TECHNICAL PARAMETERS

RATED PARAMETERS

Wall Chaser 59G371

Parameter Value

Supply voltage 230 V AC

Power supply frequency 50 Hz

Rated power 2400 W

Idle rotational speed 8000 min

-1

Backing pad diameter 150 mm

Inner diameter of blade 22,2 mm

Max. cutting depth 43 mm

Chase width 30 mm

Spindle thread diameter M8

Protection class II

Weight 6,1 kg

Year of production 2021

59G371 denes type and indication of the device

NOISE LEVEL AND VIBRATION PARAMETERS

Information regarding noise and vibration

The following levels of emitted noise, such as emitted acoustic pressure

and acoustic power level Lw

and measurement uncertainty K have

been given in the instruction manual as dened in the EN 60745-1

standard.

The following vibration value (acceleration value) a

and measurement

uncertainty K have been determined as dened in the EN 60745-2-22

standard.

The vibration level provided in this instruction manual have been

determined according to the measurement procedure as dened in the

EN 60745-1 standard and can be used for comparison of power tools.

This can be used for preliminary assessment of exposure to vibrations.

The provided vibration level is representative for main applications of

the power tool. If the power tool is used for other applications or with

other working tools, and if it is not suciently maintained, the vibration

level may vary. The aforementioned reasons may increase the exposure

to vibrations during the entire operating period.

In order to precisely estimate the exposure to vibrations, periods should

be accounted for, in which the power tool is switched o, or when it

is switched on, but not operated. Thus, the total exposure to vibration

may prove considerably lower.

Additional safety measures should be taken to protect the user against

eects of vibrations, such as: maintenance of the power tool and its

working tools, ensuring proper temperature of the hands and proper

organisation of work.

Sound pressure level Lp

= 97 dB(A) K=3dB(A)

Sound power level Lw

= 108 dB(A) K=3dB(A)

Vibration acceleration: a

= 10,94 m/s

K=1,5 m/s

ENVIRONMENTAL PROTECTION

Electrically powered products should not be disposed of with household

wastes, but should be utilised in proper recycling centres. Obtain

information on waste recycling from your seller or local authorities. Used

electric and electronic equipment contains substances active in the natural

environment. Unrecycled equipment constitutes a potential risk for the

environment and human health.

* The right to make changes is reserved.

“Grupa Topex Spółka z ograniczoną odpowiedzialnością” Spółka komandytowa with seat in Warsaw at

ul. Pograniczna 2/4 (hereinafter Grupa Topex) informs, that all copyrights to this instruction (hereinafter

Instruction), including, but not limited to, text, photographies, schemes, drawings and layout of the

instruction, belong to Grupa Topex exclusively and are protected by laws accordingly to Copyright and

Related Rights Act of 4 February 2004 (ustawa o prawie autorskim i prawach pokrewnych, Dz. U. 2006 No

90 item 631 with later ammendments). Copying, processing, publishing, modications for commercial

purposes of the entire Instruction or its parts without written permission of Grupa Topex are strictly

forbidden and may cause civil and legal liability.
