3 Push the hose onto the G 1 ½ pump connecting

piece and fasten it with a hose clamp.

4 Push the connection nozzle into the Quick-Connect.

Illustration C

Erecting/immersing the pump:

1 Push the level sensor onto the rail from above.

Illustration D

2 Fold the feet out or in. (SP 17000 Flat Level Sensor)

Illustration E

Note

The feet do not necessarily need for be folded out bit

folding out the feet provides a higher delivery rate. Fold-

ing the feet in allows flat suction of liquids to a residual

fluid height of 1 mm.

3 Installing/removing the pre-filter. (SP 17000 Flat

Level Sensor)

Illustration E

Note

It is not necessary to install the pre-filter, but a higher

delivery rate is reached by installing the pre-filter (only

for SP 17000 Flat Level Sensor). The pumped liquid is

pre-filtered by the pre-filter to protect the pump from

heavy contamination. Particles of up to 5 mm can still be

pumped when using the filter. Removing the pre-filter al-

lows flat suction of liquids to a residual fluid height of

1 mm. (only for SP 17000 Flat Level Sensor).

4 Place the pump securely on solid ground in the

pumped liquid or immerse it via a rope attached to

the carrying handle.

Note

The suction area must not be blocked by soiling. If the

ground is muddy, place the pump on a brick or similar.

Make sure that the pump stands level. Do not carry the

pump using the cable or hose.

Operation

 DANGER

Danger of death from electric shock.

Danger of death from electric shock if live parts are

touched.

During operation, do not touch the rope attached to the

carrying handle or any objects that are in contact with

the pumped liquid (e.g. pipelines protruding into the

pumped liquid, railings) and do not reach into the

pumped liquid.

Automatic venting device

1. If the fluid level is low, any sucked-in air, or air pres-

ent in the pump, may escape via the automatic vent-

ing device. Fluid can also leak along with air.

If the pump has problems with suction when the fluid

level is low, unplug and plug in the mains plug re-

peatedly to assist the suction process.

Illustration F

Automatic mode

Note

In automatic mode, the level sensor controls the pump-

ing process automatically. The pump switches on when

the level sensor makes contact with the rising pumped

liquid.

The pump switches off when the level sensor loses con-

tact with the falling pumped liquid and an after-running

time of 15 s has expired.

Illustration G

Switching on:

Minimum fluid level required to enable the pump to suck

independently (= minimum switch-on point):

● SP 17000 Flat Level Sensor: 7 mm (57 mm when

using the pre-filter)

● SP 22000 Dirt Level Sensor: 50 mm

Highest adjustable switching height of the level

sensor:

● SP 17000 Flat Level Sensor: 190 mm (240 mm

when using the pre-filter)

● SP 22000 Dirt Level Sensor: 237 mm

Minimum residual fluid height/max. suction depth:

● SP 17000 Flat Level Sensor: 1 mm (without pre-fil-

ter, with folded feet)

● SP 22000 Dirt Level Sensor: 35 mm

Note

It is recommended to use the pre-filter.

Note

Make sure that the pump stands level. Otherwise the

level sensor may not lose contact with the fluid and the

pump can run dry.

1. Push the level sensor to the desired switch

-on

height (contact with the pumped liquid).

Note

The higher the level sensor is set, the higher the switch-

on and switch-off points. See the following table for ap-

plication examples:

2. Set the switch to Automatic mode (AUTO).

Illustration H

3. Plug the mains plug into a mains socket.

Manual mode

Note

In manual mode, the pump stays switched on.

1. Set the switch to Manual mode (MAN).

Illustration H

2. Plug the mains plug into a mains socket.

ATTENTION

Risk of damage from dry running!

Dry running leads to increased wear on the pump.

Do not leave the pump unattended in manual operation.

In case of dry running, immediately pull the mains plug

out of the socket.

Application area SP 17000 Flat

Level Sensor

SP 22000 Dirt

Level Sensor

Shafts with a di-

ameter < approx.

1 m (e.g. drain-

age)

Level sensor in

uppermost posi-

tion

Level sensor in

uppermost posi-

tion

We recommend-

ed using the pre-

filter

Pre-filter flap

closed (protection

against soiling)

Swimming pools,

ponds (only for

SP 22000 Dirt

Level Sensor)

Level sensor in

lowest position

Level sensor in

lowest position

Starting pumping

with the pre-filter

or folded-out feet

Pre-filter flap

closed (protection

against soiling)

Continuing pump-

ing without the

pre-filter and fold-

ed-in feet (reach-

es a residual fluid

height of 1 mm)

Note

Perform in manu-

al mode. Monitor

the switch-off/

shallow suction.
