Table of contents
21
Climate Line 2000 – 6721831695 (2021/02)
Table of contents 1 Explanation of symbols and safety instructions
1.1 Explanation of symbols
Warnings
In warnings, signal words at the beginning of a warning are used to
indicate the type and seriousness of the ensuing risk if measures for
minimizing danger are not taken.
The following signal words are defined and can be used in this document:
DANGER
DANGER indicates that severe or life-threatening personal injury will
occur.
WARNING
WARNING indicates that severe to life-threatening personal injury may
occur.
CAUTION
CAUTION indicates that minor to medium personal injury may occur.
NOTICE
NOTICE indicates that material damage may occur.
Important information
The info symbol indicates important information where there is no risk to
people or property.
The product is manufactured in China.
1 Explanation of symbols and safety instructions . . . . . . . . . .21
1.1 Explanation of symbols . . . . . . . . . . . . . . . . . . . . . . . . .21
1.2 General safety instructions . . . . . . . . . . . . . . . . . . . . . .22
1.3 Notices regarding these instructions. . . . . . . . . . . . . . .23
2 Product Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
2.1 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
2.2 Product dimensions and minimum clearances. . . . . . .23
2.2.1 Indoor unit and outdoor unit . . . . . . . . . . . . . . . . . . . . .23
2.2.2 Refrigerant pipes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
3 Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
3.1 Before installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
3.2 Requirements for installation site . . . . . . . . . . . . . . . . .24
3.3 Unit installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
3.3.1 Installing the indoor unit . . . . . . . . . . . . . . . . . . . . . . . .24
3.3.2 Installing the outdoor unit . . . . . . . . . . . . . . . . . . . . . . .24
3.4 Pipework connection . . . . . . . . . . . . . . . . . . . . . . . . . . .25
3.4.1 Connecting refrigerant lines to the indoor and
outdoor unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
3.4.2 Connecting condensate pipe to the indoor unit . . . . . .25
3.4.3 Checking tightness and filling the system. . . . . . . . . . .25
3.5 Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . .26
3.5.1 General notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
3.5.2 CLL2000-Set 23/26/35/53 W: connecting the
cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
3.5.3 CLL2000-Set 70 W: connecting the cables . . . . . . . . .26
4 Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
4.1 Commissioning checklist . . . . . . . . . . . . . . . . . . . . . . . .27
4.2 Functional test of device . . . . . . . . . . . . . . . . . . . . . . . .27
4.3 Handover to the user . . . . . . . . . . . . . . . . . . . . . . . . . . .27
5 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
5.1 Faults with indication . . . . . . . . . . . . . . . . . . . . . . . . . . .28
5.2 Faults without indication . . . . . . . . . . . . . . . . . . . . . . . .28
6 Environmental protection and disposal . . . . . . . . . . . . . . . . .29
7 Technical Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
