-25~+75℃(Refer to”Derating Curve”)

5 ~ 95% RH non-condensing

-25~+80℃

±0.03%/℃ (0 ~ 75℃)

5000 Ⅱ meters /OVC

IEC60068-2-27,30G (300m/S²) for a duration of18ms,1 time per direction,2 times in total

IP/OP-FG:2.2KVdc; Signals-FG:2.2KVdc

IEC62368-1,UL62368-1 approved

Parameter

ESD

Radiated

EFT / Burst

Surge

Conducted

Magnetic Field

Conducted

Radiated

Harmonic Current

Standard

BS EN/EN55032

BS EN/EN61000-4-2

BS EN/EN61000-4-3

BS EN/EN61000-4-4

BS EN/EN61000-4-5

BS EN/EN61000-4-6

BS EN/EN61000-4-8

Test Level / Note

Class B

-----

EN55035, EN61000-6-2BS EN/ BS EN/

Level 4, 15KV air ; Level 3, 8KV contact; criteria A

Level 3, 10V/m ; criteria A

Level 4, 30A/m ; criteria A

Level 3, 10V ; criteria A

Level 3, 2KV ; criteria A

Voltage Flicker

-----

Level 3, 1KV/Line-Line ;Level 3, 2KV/Line-Line-FG ;criteria A

-----

MTBF

DIMENSION

OTHERS

NOTE

PACKING

63*125.2*114.9mm (W*H*D)

℃

μμ



℃℃







http://www.meanwell.com)

※： https://www.meanwell.com/serviceDisclaimer.aspx

SAFETY STANDARDS

WORKING TEMP.

WORKING HUMIDITY

STORAGE TEMP.

TEMP. COEFFICIENT

VIBRATION

WITHSTAND VOLTAGE

EMC IMMUNITY

EMC EMISSION

SHOCK TEST

ENVIRONMENT

SAFETY &

EMC

(Note.4)

OPERATING ALTITUDE Note.3

File Name:DBUF40-24-SPEC 2022-03-18

162.6K hrs min. MIL-HDBK-217F (25℃) ; 1420.2K hrs min. Telcordia TR/SR-332 (Bellcore) (25℃)

1.062Kg; 12pcs/12.8Kg/0.74CUFT

Component: 10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes;

Mounting clip: Compliance to IEC60068-2-6

IP/OP-FG,Signals-FG:>100M Ohms / 500Vdc / 25 / 70% RH℃

ISOLATION RESISTANCE

DBUF40-24

24V/40A DIN Rail Type Buffer Module

106.8K hrs min. MIL-HDBK-217F (40℃) ; 717.2K hrs min. Telcordia TR/SR-332 (Bellcore) (40℃)
