Pro repair clamp,

auto adjustable 1693.1

Clamps diameters

from 24 to 32 mm

Jaws of the clamp are automatically

adjusted by spring.

To clamp the part just insert the

clamped part between the jaws and

close it with the handle.

To release the part, open the handle.

Works best when clamping lots of

bikes with traditional aluminum or

steel seat post.

For clamping carbon or dropper

seat posts consider using 1693.1S or

1693.1Q

Pro repair clamp,

manually adjustable 1693.1S

Clamps diameters

from 24 to 38 mm

Jaws of the clamp need to be

manually adjusted by turning the nut

on the clamp.

To clamp the part insert the clamped

part between the jaws, manually

adjust the opening of the jaws with

the nut to the appropriate diameter

and close it with the lever.

To release the part, open the handle.

Suitable for clamping any kind of

parts even carbon and dropper seat

posts.

Compared to 1693.1Q takes more

time to clamp parts and don´t have

so sophisticated clamping force

modulation.

For faster and more precise work

consider using 1693.1Q

Pro shop clamp 1693.1Q Clamps diameters

from 22 to 60 mm

Insert clamped part between jaws

and squeeze them together, to get

them closer to the clamped part.

Turn the handle clockwise, so the

clamp will rmly grab the clamped

part between the jaws. By turning the

handle you can simply control the

clamping force.

To release the clamp, turn the handle

counterclockwise and release the

button on the other side of the clamp.

Most sophisticated clamp in our

oering with quick clamping

action and precise clamping force

modulation.

Suitable for clamping even the most

sensitive parts.

*all clamps are compatible with all models of Unior bike repair stands

Unior clamps 1693 explained
