Ritar EV12-45 Описание АКБ ev12-45 онлайн

Ritar EV12-45 Описание АКБ ev12-45 онлайн
Constant Current Discharge Characteristics : A(25 )℃
Constant Power Discharge Characteristics : W/Cell(25 )℃
Dimensions
Specification
EV12-45(12V45Ah)
Cells Per Unit
6
Voltage Per Unit
12V
Capacity
45Ah@20hour-rate to 1.75V per cell @25℃
Weight
Approx. 14.0 Kg (Tolerance±5%)
Max. Discharge Current
450A (5 sec)
Internal Resistance
≤7.0 mΩ (Full Charge Condition @25℃)
Terminal
Default F11(M6), F4(M5) Optional
Maxi. Charging Current
13.5A
Container Material
A.B.S. UL94-HB, UL94-V0 Optional.
Operating Temperature Range
Discharge: -20℃~60℃
Charge: 0 ~50℃ ℃
Storage: -20 ~60℃ ℃
Normal Operating Temperature Range
25 ±5℃ ℃
Float Charging Voltage
13.6 V~13.8 V @ 25℃
14.6 V~14.8 V @ 25℃
Cycle Use Voltage
Self Discharge
RITAR Valve Regulated Lead Acid (VRLA) batteries can
be stored for up to 6 months at 25℃ and then recharging
is recommended. Monthly Self-discharge ratio is less
than 3% at 25℃.Please charged batteries before using.
Reference Capacity
Cold Cranking Ampere(CCA)
315A
Temperature Compensation: -3mV/℃/Cell
Temperature Compensation: -4mV/℃/Cell
(Note) The above characteristics data are average values obtained within three charge/discharge cycle not the minimum values.
The battery must be fully charged before the capacity test. The C20 should reach 95% after the first cycle and 100% after the third cycle.
EV ( Electric Vehicle ) series is specially
designed for frequent discharge deep cycle
application. By using the specially designed
active material, strong grids and thick plate
construction, the EV series battery offers
reliable performance in high load situations
an d co ul d pr ov id e co mp et it iv e cy cl e
performance. Electric
Vehicle and Golf cart, Floor Machines,
Forklifts, Aerial lifts, Robotics, Marine, RV,
Mobility and Medical Equipment, and most
outdoor application.
It is suitable for
C3 33.6Ah
C20 45.0Ah
C5 38.3Ah
C10 42.8Ah
ISO 90 01 ISO 14 001 ISO 45 001
MH 28539
BSTXD210316008503EC
Length
Width
Height
Total Height
198±2mm (7.80 inches)
166±2mm (6.54 inches)
169±2mm (6.65 inches)
169±2mm (6.65 inches)
Terminal
M5
M6
M8
Value
6~7 N*m
8~10 N*m
10~12 N*m
Unit: mm
5
F11 TERMINAL
198
169
M6
Φ14
166
154.5
51
F.V/Time 5MIN 10MIN 15MIN 30MIN 1HR 2HR 3HR 4HR 5HR 8HR 10HR 20HR
1.60V 151.4 114.2 85.9 50.3 27.5 16.3 12.7 9.97 8.49 5.58 4.51 2.34
1.65V 145.9 107.9 82.2 48.3 26.6 15.8 12.3 9.70 8.27 5.52 4.45 2.31
1.70V 138.8 99.4 77.0 46.1 25.7 15.3 12.0 9.44 8.05 5.43 4.39 2.28
1.75V 129.6 91.0 71.6 44.1 24.7 14.7 11.6 9.20 7.85 5.36 4.33 2.25
1.80V 118.1 82.3 66.1 42.1 23.8 14.2 11.2 8.93 7.65 5.27 4.28 2.23
1.85V 103.9 67.3 54.9 36.3 21.3 13.0 10.4 8.30 7.13 4.94 4.02 2.11
F.V/Time 5MIN 10MIN 15MIN 30MIN 1HR 2HR 3HR 4HR 5HR 8HR 10HR 20HR
1.60V 260.5 194.2 150.2 91.3 51.7 30.9 24.2 19.1 16.4 10.9 8.87 4.61
1.65V 257.8 187.0 145.8 88.6 50.2 30.1 23.6 18.7 16.0 10.8 8.77 4.55
1.70V 248.0 175.3 138.6 85.5 48.9 29.2 23.0 18.3 15.6 10.7 8.65 4.50
1.75V 235.8 163.4 130.8 82.6 47.4 28.3 22.5 17.9 15.3 10.5 8.55 4.45
1.80V 218.6 150.5 122.5 79.7 45.8 27.5 21.8 17.4 15.0 10.4 8.45 4.41
1.85V 195.8 125.2 103.1 69.3 41.3 25.3 20.3 16.2 14.0 9.76 7.96 4.19
