ENGLISH

www.euroteplo.ru

CONTENT

1. General ........................................................................ 20

2. Designation of Underfloor Heating Mat .................. 21

3. Underfloor Heating Mat Contents .......................... 21

4. Installation Conditions............................................... 21

5. Installation Tools ....................................................... 21

6. Heatline® Underfloor Heating Mat ........................... 21

7. Thermostat .................................................................. 22

8. Preparation for Installation ....................................... 22

9. Wiring System ............................................................. 22

10. Heatline® Underfloor Heating Mat Installation ....... 22

10.1. Heatline® Heating Mat Installation ........................... 23

10.2. Procedure for Connecting Heatline® Single-Core

Wire Underfloor Heating Mat to the Thermostat .... 23

10.3. Procedure for Connecting Heatline® Double-Core

Wire Underfloor Heating Mat to the Thermostat .... 24

11. Heatline® Underfloor Heating Mat

Switch Connection and Operation .......................... 24

12. Safety ........................................................................... 24

13. Heatline® Underfloor Heating Mat Parameters ...... 25

14. Warranty Certificate (to be filled in by trade

companies and installation companies) ................. 26

15. Statement of warranty ............................................... 26

16. Test Certificate ........................................................... 27

17. Manufacturer .............................................................. 27

1. GENERAL

Thank you for buying Heatline® Underfloor Heating Mats

manufactured by HEATLINE Manufacturing Company

LLC, Russia.

Using the most up-to-date technologies and materials

of the highest quality when manufacturing this product

has made Heatline® trademark popular and trustworthy.

Heatline® Underfloor Heating Mats are manufactured in

strict compliance with international standards guaranteeing

reliability and safety. The manufacturer, HEAT LINE

Manufacturing Company LLC, has international GOST ISO

9001-2011 (ISO 9001:2008) GOST Р ISO 14001-2007 (ISO

14001:2004) GOST 12.0.230-2007 (04SAS 1800:2007)

quality certificate.

• Before installing the Kit, carefully read this instruction

manual that gives step by step directions for install-

ing the Heatline® Underfloor Heating Mats.

• The heating Mats and the temperature controller

should be installed ONLY by a trained professional

(electrician), who has relevant professional experience

and the proper tools to do the work!

• Neither the manufacturer, nor the retailer takes

ANY responsibility for ANY breakdowns, poor con-

ditions, injuries, or permanent disabilities caused by

the improper installation of this equipment!

• Read the label details and compare the type of the

Underfloor Heating Mats mentioned on the label

with the type on the box. Make sure that the Kit

you have chosen fits your rooms. It is important

to take careful measurements. Keep the label and

related paperwork until the end of the warranty

period. Without the label the warranty is INVALID!

DESIGNATIONS EMPLOYED:

Please look at the legends used in the manual:

Prohibited.

Used to designate a prohibition of an

action. A failure to comply with this recommendation

may cause this product to malfunction and cause

personal injury.

Important. Used for specifically important items

and installation rules.

Note. This symbol marks additional useful

information that is not necessarily related to the

purchased product directly.

MC LLC.

Reproduction, transfer, distribution, translation or

any other processing, including electronic and

digital, of this guide or any of its parts, is prohibited

without prior written consent of HEAT LINE MC LLC.

TRADEMARK

logo is a registered trademark of HEAT

LINE MC LLC

2. DESIGNATION

OF UNDERFLOOR HEATING MAT

Heatline® thin Underfloor Heating Mats are designed

to provide an additional heat source in rooms with a

ceiling height of no more than 4 meters. The heat supply

is a heating unit attached to a special fiberglass mesh

and laid in brick glue. It can be used on any floors with

concrete foundation including where there are floor

structure height limitations (it doesn’t require screed

coating).

If you are going to heat a balcony, a recessed balcony,

a winter garden, a room with 4 m ceiling or higher,

or plan to use electric underfloor heating as a main

source of heat, seek professional advice from HEAT

LINE MC LLC at 8-800-333-58-25 (free from the

Russian Federation).

3. UNDERFLOOR HEATING MAT

CONTENTS (FIGURE А1)

The Heatline® Thin Underfloor Heating Mats (Figure А1)

include the following components:

1. HL PPPP-SS single-core heating mat, where PPPP

is nameplate power, W, SS is mat area, m

MS PPPP-SS double-core heating mat, where PPPP

is nameplate power, W, SS is a mat area, m

2. Flexible corrugated pipe for temperature sensor

installation.

3. Passport manual for underfloor electric heating

system installation.

4. Inner label.

5. Packaging.

4. INSTALLATION CONDITION

The installation is allowed at room temperatures not

lower than +10

С and relative humidity not more than

80%.

5. INSTALLATION TOOLS

5.1. Perforating puncher/hammer drill.

5.2. Slitting tool/wall chaser.

5.3. Flat nose pliers.

5.4. Cutting pliers.

5.5. Crimping pliers.

5.6. Set of screwdrivers.

5.7. Stripper.

5.8. Ohmmeter.

5.9. Megohmmeter.

5.10. Tester (voltage detector).

5.11. Tape ruler.

5.12. Earthing switch.

5.13. Lead pencil.

5.14. Painter’s tape.

6. HEATLINE® UNDERFLOOR

HEATINGMAT

A heating mat is a heating unit made of a shielded

single-core or double-core heating cable attached

to fiberglass mesh. It includes installation wiring and

reliable sleeve couplings.Since the cable is already

attached to the mesh, selection of installation spacing

is not required. This reduces the risk of damage during

installation.

Mats parameters are mentioned in section 13 on

page 25
