Levenhuk Skyline AZ Telescopes

Congratulations on your purchase of a high-quality Levenhuk telescope!

These instructions will help you set up, properly use, and care for your telescope. Please read them

thoroughly before getting started.

CAUTION! Never look directly at the Sun – even for an instant – through your telescope or nderscope without a

professionally made solar lter that completely covers the front of the instrument, or permanent eye damage

may result. To avoid damage to the internal parts of your telescope, make sure the front end of the nderscope

is covered with aluminum foil or another non-transparent material.

Children should use the telescope under adult supervision only.

All parts of the telescope will arrive in one box. Be careful when unpacking it. We recommend keeping

the original shipping containers. In the event that the telescope needs to be shipped to another

location, having the proper shipping containers will help ensure that your telescope survives the

journey intact. Make sure all the parts are present in the packaging. Be sure to check the box carefully,

as some parts are small. No tools are needed other than those provided. All screws should be tightened

securely to eliminate exing and wobbling, but be careful not to overtighten them, as that may strip

the threads.

During assembly (and anytime, for that matter), do not touch the surfaces of the optical elements

with your ngers. The optical surfaces have delicate coatings on them that can easily be damaged if

touched. Never remove lenses or mirrors from their housing, or the product warranty will be null and

void.

Tripod assembly

• Slowly loosen the tripod locking knobs and gently pull out the lower section of each tripod leg.

Tighten the screws to hold the legs in place.

• Spread the tripod legs apart to stand the tripod upright.

• Adjust the height of each tripod leg until the tripod head is properly leveled. Note that the tripod

legs may not be the same length when the mount is leveled.

• Place the accessory tray on top of the bracket, and secure it with thumbscrews from underneath.

For Levenhuk Skyline 50x600 AZ, 60x700 AZ: secure the accessory tray with one screw in the middle

of the tray.

Diagonal mirror and eyepiece assembly

Refractors: Loosen the focuser thumbscrew. Insert the diagonal mirror into the focuser tube and

retighten the thumbscrew to hold the diagonal mirror in place. Then insert the desired eyepiece into

the diagonal mirror and secure it by retightening the thumbscrew.

Reectors: Loosen the focuser thumbscrew. Take o the plastic cap from the eyepiece tube. Insert the

selected eyepiece and secure it by retightening the thumbscrew.

Telescope assembly (models with fork mount)

• Remove the locking screw from the slow-motion control rod.

• Insert the rod into the hole on the side of the fork mount.

• Place the telescope tube between fork arms so that holes on the tube match the arm holes. Fasten

the telescope tube to the mount with thumbscrews.

• Fasten the other end of the rod to the telescope tube by inserting the screw through shaft and tube

holes and tightening it.

Telescope assembly (50x600 AZ)

• Remove the altitude lock knob from the mount head.

• Place the telescope optical tube on the altazimuth mount so that the hole in the optical tube lines

up with the hole in the mount head.

• Insert the altitude lock knob through the mount head and optical tube. Make sure the hole is clear

all the way through before tightening the knob. Secure the altitude lock knob.
