Levenhuk Skyline BASE Telescopes

CAUTION! Never look directly at the Sun — even for an instant — through your telescope or nderscope without a

professionally made solar lter that completely covers the front of the instrument, or permanent eye damage may result.

To avoid damage to the internal parts of your telescope, make sure the front end of the nderscope is covered with

aluminum foil or another non-transparent material. Children should use the telescope under adult supervision only.

All parts of the telescope will arrive in one box. Be careful when unpacking it. We recommend keeping the

original shipping containers. In the event that the telescope needs to be shipped to another location, having

the proper shipping containers will help ensure that your telescope survives the journey intact. Make sure

all the parts are present in the packaging. Be sure to check the box carefully, as some parts are small. No

tools are needed other than those provided. All screws should be tightened securely to eliminate exing and

wobbling, but be careful not to overtighten them, as that may strip the threads.

During assembly (and anytime, for that matter), do not touch the surfaces of the optical elements with your

ngers. The optical surfaces have delicate coatings on them that can easily be damaged if touched. Never

remove lenses or mirrors from their housing, or the product warranty will be null and void.

Telescope optical system and construction

Levenhuk Skyline BASE is a series of easy to use entry-level telescopes. These telescopes are perfect for kids

and beginners in astronomy. Reectors are good for studying solar system and bright deep-sky objects, while

refractors are suitable for planetary observations as well as for studying terrestrial objects.

This user manual is applicable to several refractor (g. 1a) and reector telescopes (g. 1b, 1c) on

alt-azimuth mounts. Read the user manual carefully to nd the information about the assembling and

adjustment of your telescope model, and carefully follow the instructions.

Tripod assembly

• Slowly loosen the tripod locking knobs and gently pull out the lower section of each tripod leg.Tighten

the screws to hold the legs in place.

• Spread the tripod legs apart to stand the tripod upright.

• Adjust the height of each tripod leg until the tripod head is properly leveled. Note that the tripod legs

may not be the same length when the mount is leveled.

• Place the accessory tray on top of the bracket, and secure it with thumbscrews from underneath

(g. 2a) or secure the accessory tray with one screw in the middle of the tray (g. 2b).

Mount assembly

Fork mount (g. 3a):

• Remove the locking screw from the slow-motion control rod.

• Insert the rod into the hole on the side of the fork mount.

• Place the telescope tube between fork arms so that holes on the tube match the arm holes. Fasten the

telescope tube to the mount with thumbscrews.

• Fasten the other end of the rod to the telescope tube by inserting the screw through shaft and tube

holes and tightening it.

Mount without a fork (g. 3b):

• Remove the altitude lock knob from the mount head.

• Place the telescope optical tube on the altazimuth mount so that the hole in the optical tube lines up

with the hole in the mount head.

• Insert the altitude lock knob through the mount head and optical tube. Make sure the hole is clear all

the way through before tightening the knob. Secure the altitude lock knob.

Ring clamps mount (g. 3c):

• Remove the ring clamps from the telescope by releasing their thumbscrews and opening their hinges.

• Using the bolts provided, fasten the ring clamps to the mount with a wrench.

• Place the telescope tube between the rings and balance it.

• Close the hinges around the telescope and retighten the thumbscrews. Do not overtighten.
