Diagonal mirror

Insert the diagonal mirror into the focuser.

Eyepiece

After the diagonal mirror is inserted, place the eyepiece (20 mm) into the diagonal. The lower the number on the eyepiece, the

higher the power your telescope will be using. Plus, you decrease the eld of view and the brightness of your image. When using

eyepieces, we suggest always starting with the lowest power and then going up. Eyepieces 20 mm are ideal for all terrestrial

and astronomical observations, and eyepieces 6mm are recommended for use at nights with steady seeing.

Barlow lens

The Barlow lens is used to achieve the maximum power from your telescope. First, remove the diagonal mirror from the focusing

tube and insert the Barlow lens directly into the focusing tube. You will have to readjust the focusing since you have increased/

decreased the power of your telescope dramatically.

Finder

Loosen thumb screws on side of nder and slide nder onto dovetail mount located at top of main telescope tube. Tighten

thumb screws.

Red dot nderer

During the day light hours, point the main tube at an object at the distance of at least 300 m from you and bring it into focus.

Once you have centered the object in the main tube, tighten all knobs and adjustments to prevent any movement. Remove

circular battery saver located beneath the front of the nder (be sure to save and replace the battery saver when not in use).

Turn nder on by sliding the ON/OFF switch forward. The ON/OFF switch is located on the right side of the nder. Look through

the nder and locate the red dot. If the object in the red dot nder is not the object you see through the main tube, adjustment

is required. To move the red dot up and down, simply turn the elevation screw located on the rear bottom of the nder to the

height required. To move the red dot left and right, simply turn the windage screw located at the front left side of the nder to

the proper position. These adjustments will allow you to position the red dot on the same object centered in the main tube.

Focusing tube

Turn focusing knobs toward the telescope until it will not go further. Then focus the image by turning focusing knobs toward your

body, slowly, until the image is clear.

Note: you must have an eyepiece and diagonal mirror inserted in order to view image.

Specications

Levenhuk Strike 50 NG Levenhuk Strike 60 NG Levenhuk Strike 80 NG

Optical design achromatic refractor

Objective lens diameter

(aperture), mm

50 60 80

Focal length, mm 600 700 720

Focal ratio f/12.0 f/11.7 f/9.0

Highest practical power, x 200 233 360

Limiting stellar magnitude 10.6 10.2 11.5

Resolution threshold 2.8" 2.5'' 1.6''

Mount

Yoke altazimuth Yoke altazimuth with declination axis

Eyepieces diameter 0.965" 0.965" 1.25"

Eyepieces

F20mm, F6mm

Finder scope optical 3x20 red dot

Tripod, in / mm steel, 24.8–42.52 / 630–1080

Levenhuk reserves the right to modify or discontinue any product without prior notice.
