INTRODUCTION

Infrared thermometer ADA Tempro VISION 120 is designed to measure and

visualize the temperature distribution on the surfaces of the object of study

by a non-contact method. The device allows you to capture infrared (IR) images

along with measured / additional data and save them on a memory card for

further analysis of the received data, as well as reporting.

SPECIFICATION

IR image & Optical

Detector type ..................................................

Spectral ............................................................

Frame Rate ......................................................

Thermal Sensitivity / NETD ............................

Focal Length ....................................................

Field of view(FOV) ...........................................

Spatial Resolution(IFOV) ................................

D:S ....................................................................

Focus ................................................................

Image Display

Display ................................

Display Resolution .............

Image Model .......................

Color Palettes .....................

Temperature Measurement

Temperature Range ...........

Accuracy ..............................

English

120×90

7.5~14μm

25Hz/9Hz

60 mk

2.28mm/F1.13

50°×38°

7.6 mrad

130:1

xed focus

2.4 inch IPS technology TFT display

240×320

IR image

6:White Hot, Iron Red, Hot Iron, Arctic, Rain-

bow 1, Rainbow 2

-20°C-150°C, 100°C-400°C (Auto switching)

±2°C or ±2%, whichever is greater

( target temp ≥0°C, ambient temp is 15°C ~ 30°C )
