EN 10

Operating manual – thermohygrometer TC100

7. Now switch the device off and back on to proceed with the

changed settings.

Relative humidity:

1. Switch the device off.

2. Simultaneously press and hold the MODE button(10) and

the Lamp/ pressure unit button(8), then briefly actuate the

Power button(3) as well.

ð The value "0.0" will appear on the display(1).

3. Let go of the MODE(10) and the Lamp/ pressure unit

button(8).

4. Now you can increase the relative humidity threshold by

holding down the MAX/MIN button(4) and briefly actuating

the HOLD button(2) as well.

ð The threshold value will increase in steps of 0.1.

5. You can reduce the relative humidity threshold by holding

down the MAX/MIN button(4) and briefly actuating the

Lamp/ pressure unit button(8) in addition.

ð The threshold value will decrease in steps of 0.1.

6. Simultaneously press the MODE(10) and the Power

button(3) to save the adjusted threshold value.

ð The message "Save" will briefly appear on the

display(1) to confirm that the selected threshold value

has been set.

7. Now switch the device off and back on to proceed with the

changed settings.

Saving and calling up measuring results

The device memory permits you to save up to 99measuring

results. Please proceed as follows to save a measured value:

1. Briefly press the SET button(9).

ð "Rec" will briefly appear on the display(1) beside the

measurement value display for air temperature(16).

ð The slot, i.e. memory location, for the just saved

measured value will be indicated for approx. 2seconds

on the display in place of the air pressure value(20).

Please proceed as follows to call up a saved measuring result:

1. Press and hold the MODE button(10) for approx.

3seconds.

ð The measuring result most recently saved in slot "01"

will be displayed.

2. You can use the HOLD button(2) and the Lamp/ pressure

unit button(8) to browse the list of saved measuring

results.

Deleting saved measuring results

All saved measuring results can be deleted at any time. This

means, however, that all saved measuring results will be

deleted at once, not just individual ones.

Proceed as follows to delete the saved measuring results on the

device:

1. Press and hold the MODE button(10) for approx.

3seconds.

ð The measuring result most recently saved in slot "01"

will be displayed.

2. Press and hold the SET button(9) for approx. 2seconds.

ð All saved measuring results will be deleted.

ð "- - -" will be indicated for the measuring results on the

display(1) and the value for the selected memory space

is "00".

3. Press and hold the MODE button(10) twice for about

3seconds to switch back into normal measuring operation.

ð You can now resume the current measurement.

Configuring the alarm for the WBGTindex

You can define values for the WBGT index upon the exceedance

of which an acoustic alarm will be triggered. In default setting,

the alarm function is deactivated. For indoor measurements the

value can be set within a range of 15.0°C to 59.0°C, out of

doors you should set it between 15.0°C and 56.0°C.

Please proceed as follows to configure the alarm function:

1. Press and hold the MODE button(10) for approx.

3seconds.

ð The measuring result most recently saved in slot "01"

will be displayed.

2. Press and hold the MODE button(10) again for approx.

3seconds.

ð The currently set alarm threshold for the WBGTindex

will be indicated on the display(1).

3. You can use the HOLD button(2) and the Lamp/ pressure

unit button(8) to adjust the set value.

4. You can switch between the individual positions of the

segment display by briefly actuating the UNIT button(5).

5. Press and hold the MODE button(10) again for about

3seconds to switch back into normal measuring operation.

ð The set value will be saved and you can proceed with

the current measurement.
