4.3 Power-on Utilities

This printer has six power-on functions for setting or testing the printer's hardware. Press these

buttons at the same time when the power is turned on, and release the buttons with the light signal to

activate these functions.

Follow these steps to enable the boot function:

Event

Description

Post

A. Power off the printer

B. Make sure the printer is loaded with paper and close the printer cover

C. Press and hold the FEED button and turn on the printer. At this time, the

printer will print a self-test test page, and release the paper feed button.

Print settings

A. Power off the printer

B. Make sure the printer is loaded with paper and close the printer cover

C. Press and hold the PAUSE button and turn on the printer. At this time,

the printer will print the setting value page, and release the PAUSE button.

Enter debug mode

A. Power off the printer

B. Make sure the printer is loaded with paper and close the printer cover

C. Press and hold the PAUSE and FEED buttons simultaneously for two

seconds, and then turn on the printer. When the power Blue and error Red

lights are on at the same time, release the PAUSE and FEED button, when

you hear a sound, the printer will enter debug mode

Skip AUTO.BAS program

A. Power off the printer

B. Press and hold the PAUSE button and the FEED button for four seconds

at the same time, and turn on the printer power until the power Blue is off,

and the error Red is on, release the PAUSE button and FEED button, two

beeps are heard. At this time, the printer will skip the AUTO.BAS program,

and then the power light is on

Printer initialization

A. Power off the printer

B. Press and hold the PAUSE and FEED buttons simultaneously for six

seconds, and turn on the printer power until the printer power Blue is on,

and the error Red is off, release the PAUSE Key and FEED key, three

beeps are heard. At this time, the printer will clear the downloaded data in

the internal memory (DRAM) and restore the printer parameters to the

factory default settings.

Ribbon inspection

The machine will automatically detect the status of the ribbon after turning

on and in each thermal transfer printing mode.
