English

Ŷ Never reach behind or beneath the grinding wheels.

Ŷ Use ear protection, such as plugs or muffs, during

extended periods of operation.

Ŷ 5HPRYHWKHSOXJEHIRUHFDUU\LQJRXWDQ\DGMXVWPHQW

servicing or maintenance. The power cord must remain

unplugged whenever you are maintaining your bench

grinder.

Ŷ $GMXVWWKHZRUNUHVWVDQGVSDUNDUUHVWRUVIUHTXHQWO\VR

as to compensate for the wear of the grinding wheels.

Ŷ $GMXVW ZRUN UHVWV ZKHQHYHU QHFHVVDU\ WR NHHS WKH

distance between the work rests and the grinding

wheels as small as possible. This distance should

be less than or equal to 2 mm. As the diameter of

the grinding wheel decreases with use, maintain the

PD[LPXPZRUNUHVWGLVWDQFHE\DGMXVWLQJLW

Ŷ $GMXVW VSDUN DUUHVWRUV ZKHQHYHU QHFHVVDU\ WR NHHS

the distance between the spark arrestors and the

grinding wheels as small as possible. This distance

should be less than or equal to 2 mm. As the diameter

of the grinding wheel decreases with use, maintain the

PD[LPXPVSDUNDUUHVWRUGLVWDQFHE\DGMXVWLQJLW

Ŷ Replace the worn wheel when the distance of 2 mm

EHWZHHQWKHVSDUNDUUHVWRUZRUNUHVWDQGWKHZKHHODUH

no longer able to be maintained.

Ŷ If the spark arrestor or work rest becomes worn or

damaged, replace it with an identical replacement from

the authorised service centre.

Ŷ When fitting a new grinding wheel, always check that

the stated maximum RPM meets or exceeds that stated

on the grinder. Ensure the wheel diameter and arbor

size meet that stated on the specifications. Also check

the new wheel for damage, such as flaws or cracks.

GRINDING WHEEL SAFETY INSTRUCTIONS

WARNING

7RUHGXFHWKHULVNRILQMXU\XVHUPXVWUHDGDQGFRPSO\

with instructions, warnings and operator’s manual before

starting to use this grinding wheel. Failure to heed these

warnings can result in wheel breakage and serious

SHUVRQDOLQMXU\6DYHWKHVHLQVWUXFWLRQV

Ŷ The use of any wheel other than the one recommended

in the machine instruction manual may present a risk of

SHUVRQDOLQMXU\8VH RQO\JULQGLQJZKHHOVZKLFKKDYH

marked speed equal or greater to that marked on the

machine.

Ŷ Never use grinding wheel that is too thick to allow outer

flange to engage with the flats on the spindle. Larger

wheels will come in contact with the wheel guards,

while thicker wheels will prevent the bolt from securing

the wheel on the spindle. Either of these situations

could result in a serious accident and can cause serious

SHUVRQDOLQMXU\

Ŷ This wheel is for grinding and shaping metal. Do not

attempt to do cut-off operation.

Ŷ This grinding wheel is only suitable for dry grinding.

Ŷ Do not use damaged grinding wheels, do not use wheels

that are chipped, cracked or otherwise defective.

Ŷ Ensure that the abrasive grinding wheel is correctly

fitted and tightened before use.

Ŷ Machine should never be connected to power supply

when you are installing or removing grinding wheels.

Ŷ Store your spare grinding wheel carefully.

Ɣ Keep the wheel inside the original package if

possible.

Ɣ Store the wheel in a dry area at room temperature.

Ɣ Wheels may be stored vertically on a shelf.

Ɣ Do not allow the wheels to fall or suffer any impact.

Information available on the grinding wheel label

The information on the wheel label is important. Read and

check it carefully to ensure you are selecting the correct

type of wheel.

1. Manufacturer, supplier, importer or trade mark.

2. Nominal dimensions of grinding wheel, in particular the

diameter of the bore.

3. Abrasive type, grain size, grade or hardness, type of

bond and use of reinforcement.

4. Maximum operation speed in metres per second.

5. 0D[LPXPSHUPLVVLEOHVSHHGRIURWDWLRQLQPLQ

6. For declaration of conformity, the abrasive products

shall be marked with EN 12413.

7. Restriction of use and safety warning symbols.

8. 7UDFHDELOLW\ FRGH HJ $ SURGXFWLRQEDWFK QXPEHU

expiry date or series number.

The wheel may require replacement under any of the

following circumstances.

1. If the face of the grinding wheel is worn unevenly,

EHFRPHVJURRYHGRULVQRORQJHUVPRRWKDQGÀDW

2. If the diameter of the grinding wheel is no longer round.

3. If the surface of the wheel becomes loaded and dull

with workpiece material.

4. If there is any sign of damage.

5. ,ILWEHFRPHVGLI¿FXOWWRZRUNZLWK

6. ,IWKHZRUNUHVWVSDUNDUUHVWRUFDQQRWEHDGMXVWHGWR

2 mm distance from the wheel surface.

7. ,IFPRIGLVFSURWUXGHVIURPÀDQJH6HHWLSVRQSDJH

147.

RESIDUAL RISKS

Even when the product is used as prescribed, it is still

impossible to completely eliminate certain residual risk

factors. The following hazards may arise in use and the

operator should pay special attention to avoid the following:

Ŷ Risk of contact with unguarded parts of the rotating

wheel.

Ŷ Burn hazard from contact with hot wheel or work piece.

Ŷ Damage to respiratory system if effective dust mask is

not worn.

Ŷ Damage to hearing if effective hearing protection is not
