English | 29
(2)
Laser warning label
(3)
Lever for releasing the tool arm
(4)
Protective guard
(5)
Retracting blade guard
(6)
Roller
(7)
Fence
(8)
Saw table
(9)
Mounting holes
(10)
Insert plate
(11)
Locking knob for all mitre angles
(12)
Tilt protector
(13)
Angle indicator for mitre angles
(14)
Detents for standard mitre angles
(15)
Scale for mitre angle
(16)
Fastening screw for stationary saw table extension
(17)
Saw table extension (stationary)
(18)
Adjustable fence
(19)
Screw clamp
(20)
Laser unit/laser radiation outlet
(21)
Clamping handle for various bevel angles
(22)
Transport handle
(23)
Dust bag
(24)
Adjusting screw of depth stop
(25)
Depth stop
(26)
Saw blade
(27)
On/off switch
(28)
On/off switch for laser (cutting line indication)
(29)
Chip ejector
(30)
Tilt protector
(31)
Slide device
(32)
Locking lever of slide device
(33)
Holes for screw clamp
(34)
Opening for stationary saw table extension
(35)
Transport safety lock
(36)
Opening for flexible saw table extension (on the
power tool)
(37)
Spindle lock
(38)
Hex key
(39)
Clamping lever for the adjustable fence
(40)
Angle indicator for bevel angles
(41)
Scale for bevel angles
(42)
Fastening screw for tilt protector
(43)
Hex socket screw for mounting of saw blade
(44)
Clamping flange
(45)
Interior clamping flange
(46)
Wing bolt
(47)
Threaded rod
(48)
Saw table extension (flexible)
(49)
Opening for flexible saw table extension (on the
stationary saw table extension)
(50)
Slider for laser unit
(51)
Fastening screw for insert plate
Technical data
Sliding mitre saw PCM 8 S
PCM 800 S
PCM 8 ST
Article number
3 603 M10 1.. 3 603 M10 1..
Rated power input W 1200 1200
No-load speed min
-1
5000 5000
Laser type nm 650 650
mW < 1 < 1
Laser class 2 2
Divergence of laser line mrad (full angle) 1.0 1.0
Base unit − ●
Weight according to EPTA-
Procedure 01:2014
kg 11.4 18.2
A)
Protection class / II / II
Dimensions of suitable saw
blades
Saw blade diameter mm 216 216
Base blade thickness mm 1.4−1.8 1.4−1.8
Max. cutting width mm 2 2
Bosch Power Tools 1 609 92A 4DT | (06.12.2018)
