Product Information
Manufacturer LEO
Address China,Zhejiang,Wenling
XST65-200/150
Contact 0576-89988888
Date 2023/06/18
Project Name
Client Name LEO Sibir LLC
Client Addr. Novosibirsk
Item NO
Contacts Maksim Sokolov
Contact +79059301333
Part NO. 50008143
Product Picture Note
Water supply: Water filtration and transportation, the main pipeline
pressurization; Pressurization for high-rise buildings, hotels, etc.
Industry: Flushing and cleaning system, boiler feed water, cooling water
circulation, water treatment system, equipment supporting system.
water treatment: Ultrafiltration system, reverse osmosis system,
distillation system, separator,swimming pool.
Other: Air conditioning system; heating system; agricultural irrigation,fire
fighting system
Nameplate parameters
flow 62 m³/h
head 44 m
Efficiency 67 %
speed 2900 rpm
number of stages 1
Technical
Flow range (m³/h) 6.2-108m3/h
Curve tolerance ISO 9906 Annex A
Maximum lift (m) 45.5m
Maximum Altitude 1000m
Material
Impeller HT200/06Cr19Ni10
Pump inlet HT200
Pump shaft 45/06Cr19Ni10
Fan cover
O-ring NBR
Rear end cover
Connector HT200
Fan
Cover box
Supporting foot
Guard plate 06Cr19Ni10
Working conditions
Medium temperature (°C) -10°C+85°C
Max. ambient temperature (°C) +40°C
Pumped medium
Liquid without solid particles and long fiberslow viscositynon-combustiblenon-corrosion liquid or other
Critical cavitation margin(m) 3.5m
Working pressure 12bar
Installation
Structure Type Standard motor ( sleeve shaft)
Connection method Flange connection / thread-connection
Inlet diameter (mm) DN80
Outlet diameter (mm) DN65
Motor
Motor phase Three phase
-1-
