LEO LPP 80-70-18.5/2, 18,5 кВт, 380В, Qmax. 65,0 m3h, Hmax. 75 m 1953 Тех. данные онлайн

LEO LPP 80-70-18.5/2, 18,5 кВт, 380В, Qmax. 65,0 m3h, Hmax. 75 m 1953 Тех. данные онлайн

Product Information

Manufacturer LEO

Address China,Zhejiang,Wenling

LPP80-70-18.5/2

Contact

Date

Project Name

Client Name LEO Sibir LLC

Client Addr. Novosibirsk

Item NO

Contacts

Contact

Part NO. LPP80-70-18.5/2

Product Picture Note

:

CFD

Nameplate parameters

flow 45 m³/h

head 70 m

speed 2950 rpm

number of stages 1

Technical

Curve tolerance IS09906 AnnexA

Maximum lift (m) 75

Minimum usage flow (m³/ h) 5

Maximum use flow (m³/ h) 65

Material

Impeller HT200

Pump inlet HT200

Pump shaft AISI304

Mechanical seal SiC/C

O-ring NBR

Working conditions

Max. ambient temperature (°C) 40

Max. liquid temperature (°C) 90

Pumped medium

Working pressure 16bar

Installation

Inlet & Outlet Diameter DN80

Connection standard DIN

Motor

Motor phase Three phase

Protection class IP55

Motor poles 2

Insulation class F

Motor power (KW) 18.5KW

Frequency 50

Rated voltage (V) 380

Rated current (A) 34.1794859254542

Efficiency class IE3

Power factor 0.89

-1-
