English
8
STANDARD ACCESSORIES
Model Drill chuck spec. Standard accessories
DV13SS Keyed Chuck wrench ..........1
DV13VSS
Keyed Chuck wrench ..........1
Keyless
Case .........................1
Depth gauge .............1
Side handle ...............1
DV16SS Keyed
Chuck wrench ...........1
Depth gauge .............1
Side handle ...............1
DV16VSS
Keyed
Chuck wrench ...........1
Depth gauge .............1
Side handle ...............1
Keyless
Case .........................1
Depth gauge .............1
Side handle ...............1
Standard accessories are subject to change without notice.
OPTIONAL ACCESSORIES (SOLD SEPARATELY)
○ Impact Drill Bit (for concrete)
3.2 mm – 20 mm dia.
Optional accessories are subject to change without notice.
APPLICATIONS
○ By combined actions of ROTATION and IMPACT:
Boring holes in hard materials (concrete, marble,
granite, tiles, etc.)
○ By ROTATIONAL action:
Boring holes in metal, wood and plastic.
PRIOR TO OPERATION
1. Power source
Ensure that the power source to be utilized conforms
to the power requirements specifi ed on the product
nameplate.
2. Power switch
Ensure that the power switch is in the OFF position. If
the plug is connected to a receptacle while the power
switch is in the ON position, the power tool will start
operating immediately, inviting serious accident.
3. Extension cord
When the work area is removed from the power source.
Use an extension cord of suffi cient thickness and rated
capacity. The extension cord should be kept as short as
practicable.
4. Selecting the appropriate drill bit
○ When boring concrete or stone
Use the drill bits specifi ed in the Optional Accessories.
○ When boring metal or plastic
Use an ordinary metalworking drill bit.
○ When boring wood
Use an ordinary woodworking drill bit.
However, when drilling 6.5 mm or smaller holes, use a
metalworking drill bit.
5. Mounting and dismounting of the bit
For Drill chuck with chuck wrench (Fig. 1)
(1) Open the chuck jaws, and insert the bit into the chuck.
(2) Place the chuck wrench in each of the three holes in
the chuck, and turn it in the clockwise direction (viewed
from the front side). Tighten securely.
(3) To remove the bit, place the chuck wrench into one of
the holes in the chuck and turn it in the counterclockwise
direction.
PRECAUTION
Keep children and infi rm persons away.
When not in use, tools should be stored out of reach of
children and infi rm persons.
IMPACT DRILL SAFETY WARNINGS
1. Wear ear protectors when impact drilling.
Exposure to noise can cause hearing loss.
2. Use auxiliary handle(s), if supplied with the tool.
Loss of control can cause personal injury.
3. Hold power tool by insulated gripping surfaces,
when performing an operation where the cutting
accessory may contact hidden wiring or its own
cord. Cutting accessory contacting a "live" wire may
make exposed metal parts of the power tool "live" and
could give the operator an electric shock.
4. When boring concrete or similar hard materials in
IMPACT mode, turn the rotational change lever to the
R-mark. (Fig . 9)
SPECIFICATIONS
Model DV13SS DV13VSS DV16SS DV16VSS
Voltage (by areas)* (110 V, 220 V, 230 V, 240 V)
Power input* 550 W 600 W
Reversible None Yes None Yes
No load speed 2900 min
-1
0 – 2900 min
-1
2900 min
-1
0 – 2900 min
-1
Drill chuck capacity 13 mm
Capacity
Steel 13 mm
Concrete 13 mm 16 mm
Wood 20 mm 25 mm
Full load impact rate 29000 min
-1
Weight (without cord) 1.4 kg 1.5 kg
* Be sure to check the nameplate on product as it is subject to change by areas.
