Product description
EN
4
Thank you for purchasing our product. We are convinced - draw location of the mounting holes against the base,
that it will meet your expectations. We wish you trouble-free - place the fan in its destination place,
exploitation and satisfaction with the choice you made. We - tighten the screws.
also encourage you to share with us any remarks you have
regarding the product and our company. You can reach us
Exploitation:
via telephone at: +48 (34) 365 98 43 or via email at:
WD, WD II, WDD, EURO 0D fans do not require frequent and
serwis@dospel.com
detailed inspections*, they should however be inspected not
less than once a year. They are adapted to continuous
DOSPEL – leader in ventilation, would like to present you our
operation.
family of roof fans. They are centrifugal fans - WD, WD II,
WDD, EURO 0D.
* Depending on the conditions in the fan’s workplace.
Use: Maintenance:
Fans are used for exhaust ventilation. They can be used in In order to remove all impurities from the inside of the fan,
commercial establishments such as shops, restaurants and please follow the directions below:
bars, sanitary rooms as well as residential apartments and - disconnect the fan from the power supply,
industrial facilities (halls, warehouses, workshops, garages). - disassemble the fan by unscrewing the fixing screws,
- wash all parts with a damp cloth adding a small amount of
WD, WD II, EURO 0D, WDD fans allow connection of 3-speed detergent, careful not to wet the motor,
switch (3 step control of the motor speed). - accurately dry all elements of the fan using a cloth,
- mount the fan in its destination location,
- connect the fan to the power supply.
Construction:
WD, WD II, WDD – consists of:
CAUTION!
- an inductive single phase motor with operation capacitor
Connecting to the electric network should be carried out by a
with tightness class IP X4, adapted to continuous
professional electrician with SEP to 1kV qualifications!
operation S-1, characterized by silent operation in relation
Before conservation or regulation, a fan should be
to its efficiency, blades curved backward,
disconnected from the electric network! The electrical
- type of bearing: ball bearing,
installation should have a switch in which the distance
- casing made of galvanized sheet or galvanized powder
between contacts of all the poles is not less than 3 mm.
painted sheet, resistant to corrosion and mechanical
Absolute grounding of the fan is required .
damage. Static and dynamic balancing of the turbine
guarantees unfailing durability of the fan.
Precautions should be taken to avoid the inverse flow of gases
to the room from the open chimney duct or other devices
EURO 0D – consists of:
with an open fire. Fans should not be used in rooms having
- an inductive single phase, 3-speed motor with operation
increased humidity and as anti-explosion fans.
capacitor with tightness class IP X4, adapted to continuous
All maintenance activities have to be performed after
operation S-1, characterized by silent operation in relation
disconnecting the fan from the electric network, even if the
to its efficiency, blades curved backward,
fan is not working!!!
- type of bearing: ball bearing,
- casing made of ABS material resistant to corrosion and
It is prohibited to approach the fan during its operation as well
mechanical damage.
as without disconnecting the power supply from the
electrical installation.
Additionally EURO 0D is equipped with a base, protective
Assembly of the fan in a manner which is not compliant with
grille and hood. Static and dynamic balancing of a turbine
the manual or operating it even in a partially disassembled
guarantees unfailing durability of the fan.
condition is prohibited.
Grounding wire (yellow-green) has to be connected
Assembly:
!
Type: WD, WD II, WDD, EURO 0D
Check the rotational direction of the turbine when connected
- designed for installation on roofs and ventilation ducts of
in order to avoid improper operation of the device.
the exhaust ventilation.
The direction of rotations should correspond to the direction
After unpacking the fan the following have to be checked:
of the rotation arrow. In case of damage it should be repaired
- stability of the connections in connecting box,
by a specialist service.
- condition of the fan’s casing (dents, distortions),
Before starting the engine all screw connections have to be
- turbine should not touch the casing.
checked and tightened if necessary.
Above activities are recommended in order to identify
The producer reserves the right to introduce constructional
possible damages that could occur during transportation. If
changes, arising from the technical progress.
none of the above mentioned faults has been found,
assembly of the fan can be started in its destination:
- prepare electrical attachments for the fan,
(WD, WD II, WDD)
(WD,
WD II, WDD)
REW. 11. - 28.07.2017 testowa
