LEO LVR 10-18, 7,5 кВт, 380В, Qmax. 13,0 m3h, Hmax. 185 m 1934 Тех. данные онлайн

Product Information

Manufacturer LEO

Address China,Zhejiang,Wenling

LVR10-18

Contact

Date

Project Name

Client Name LEO Sibir LLC

Client Addr. Novosibirsk

Item NO

Contacts

Contact

Part NO. 50005547

Product Picture Note

LVR series verrtical multistage centrifugal pump is applicable to transfer

liquids without solid particles<0.2mm and fiberslow viscositynon-

inflammable non-explosive and not easy vaporization. Widely used in

high-rise building water supply and drainageWater filtration and

transportation, pipeline pressurization. High pressure flushing and

cleaning system. Boiler feed water, cooling water circulation, water

treatment system and other equipment supporting system.

Ultrafiltration system, reverse osmosis system, distillation system,

separator, swimming pool and other water treatment systems. Irrigation

and drip irrigation systems in agriculture. food and beverage and fire

fighting systems.

Nameplate parameters

flow 10 m³/h

head 147 m

speed 2900 rpm

number of stages 18

Technical

Flow range (m³/h) 5-13m3/h

Curve tolerance ISO 9906 Annex A

Head range (m)

Material

Impeller AISI 304

Diffuser AISI 304

Pump shaft AISI 304

Pump flange HT200

Motor base HT200

Coupling ferrous powder metallurgy

Pump barrel AISI 304

Working conditions

Medium temperature (°C) -20°C ~ +120°C

Max. ambient temperature (°C) +40°C

Pumped medium Clean water

Working pressure 25bar

Maximum inlet pressure 10bar

Installation

Connection method DIN flange

Inlet / outlet dia. DN40

Motor

Motor phase Three phase

Protection class IP55

Motor poles 2

Insulation class F

Motor power (KW) 7.5kW

Motor model YX3-132S2-2

Frequency 50Hz

Rated voltage (V) 380V

-1-
