COMPRAG Screw air compressor A-Series

Table of contest

1. Safety guidelines

1.1 Symbols used in the instructions

1.2 General safety guidelines

1.3 Safety precautions for start-up

1.4 Safety precautions during operation

1.5 Safety precautions for maintenance and repair

2. Technical data and functional description

2.1 Technical data

2.2 General description

2.3 Function diagram and main components

2.4 Functional description

2.5 Regulating system

2.6 Electrical diagram and main components

2.7Electrical connection values

3. Start up

3.1 Lifting and carrying

3.2 Dimensions

3.3 Requirements on installation area

3.4 Connection to the compressed airline

3.5 Connection to power supply

4. Operation

4.1 Controller and operating panel

4.2 Error indication

4.3 Starting the compressor

4.4 Switching off the compressor

5. Maintenance

5.1 Maintenance schedule

5.2 Checking oil level

5.3 Checking drive belt

5.4 Replacing oil and oil lter

5.5 Replacing air lter

5.6 Changing drive belt

5.7 Changing air-oil separator

5.8 Cleaning radiator

5.9 Checking suction valve

5.10 Servicing bearings of electric motor

6. Fault handling

6.1 Faults and corrective actions

7. Storage and disposal

7. 1 Storage conditions

7. 2 Disposal of oils and process condensate
