English | 21

Technical data

Digital Detector GMS 120

Article number

3601K810..

Max. detection depth

– Ferrous metals 120mm

– Non-ferrous metals (copper) 80mm

– Live wires 110−230V (with voltage applied)

50mm

– Wood 38mm

Operating temperature –10°C to +50°C

Storage temperature –20°C to +70°C

Inductive sensor

– Operating frequency range 5 ± 0.2kHz

– Max. magnetic field strength (at10m) 72dBµA/m

Capacitive sensor

– Operating frequency range 20 ± 1kHz

– Max. electric field strength (at10m) 24dBµV/m

Max. altitude 2000m

Relative air humidity max. 90%

Pollution degree according to IEC61010-1 2

Battery 1×9V6LR61

Approx. operating time 5h

Weight according to EPTA-Procedure01:2014 0.27kg

Protection rating IP54 (dust and splash-proof)

A) Depends on operating mode, material and size of the objects, as well as material and condition

of the base material

B) Lower detection depth with non-live wires

C) Only non-conductive deposits occur, whereby occasional temporary conductivity caused by

condensation is expected.

The serial number(14) on the type plate is used to clearly identify your measuring tool.

u The accuracy and detection depth of the measuring result may be negatively af-

fected if the condition of the substrate is unfavorable.

Bosch Power Tools 1 609 92A 5DB | (23.02.2021)
