Model No.DHW080 CORDLESS HIGH PRESSURE WASHER

Item Parts No. Description I/C Qty New/Old Opt. 1 Opt. 2 Note

038 161823-2 GEAR HOUSING COMPLETE 1

󳢢󳢢󳢢󳢢C10 263002-9 RUBBER PIN 4 2

039 922233-6 H.S.H.BOLT M5X20 WITH WR 4

040 126764-9 PUMP ASSEMBLY 1

󳢢󳢢󳢢󳢢D10 INC. 45-98

041 422409-0 RUBBER CUSHION 2

042 183M37-1 HOUSING SET 1

󳢢󳢢󳢢󳢢C10 809R02-9 CAUTION LABEL 1

󳢢󳢢󳢢󳢢D10 INC. 7

043 266326-2 TAPPING SCREW 4X18 11

044 855Y66-3 DHW080 NAME PLATE 1

045 183M00-4 SWITCH BOX SET 1

󳢢󳢢󳢢󳢢D10 INC. 48

046 911028-2 PAN HEAD SCREW M3X16 2

047 632N61-2 SWITCH UNIT 1

048 183M00-4 SWITCH BOX SET 1

󳢢󳢢󳢢󳢢D10 INC. 45

049 266130-9

TAPPING SCREW BIND PT

3X16

050 213706-3 O RING 67 1

051 210032-1 BALL BEARING 628DDW 1

052 221597-8 HELICAL GEAR 47 1

053 327076-5 SPINDLE 1

054 161821-6 PUMP HOUSING COMPLETE 1

055 347341-6 WOBBLE PLATE 8.5 1

056 265A34-8 H.S.H.BOLT M6X20 WITH WR 1

057 210176-7 THRUST BALL BEARING 2454 1

058 961052-5 RETAINING RING S-12 3

059 327075-7 PISTON PIN 12 3

060 347340-8 SPRING RETAINER C 3

061 232434-1 COMPRESSION SPRING 22 3

062 213706-3 O RING 67 1

063 319670-7 PISTON SYLINDER 1

064 922233-6 H.S.H.BOLT M5X20 WITH WR 4

065 213861-1 OIL SEAL 12 3

066 458323-4 SEAL HOLDER 12 3

067 422254-3 PACKING 12 3

068 161820-8 PISTON HOUSING COMPLETE 1

069 213656-2 O RING 53 1

070 458320-0 OUTFLOW VALVE 3

071 232432-5 COMPRESSION SPRING 7 3

072 458321-8 VALVE HOLDER 1

073 213379-2 O RING 21 1

Please order the parts with part number. Print Date 26/3/2020
