DWT HKS15-65 5.1.75 Схема разбора и таблица запчастей онлайн [2/3] 861000

Pos.No. Part No. Description Qty Remark

1 34728100601 Tapping screw\ST4x16F 5

2 34752000201 Pan head screw\M5x55 2

3 34746200201 Pan head screw\M5x30 1

4 36404001201 Switch 1

5 30195100201 Handle cover 1 Pos.5,6 supplied as a set

6 30195000201 Handle support 1 Pos.5,6 supplied as a set

7 35226700101 Ring terminal\φ12xφ16xφ2 2

9 22402800101 Cord clamp 1

10 42088300901 Rating label 1

11 32002300201 Cord sleeve 1

12 23616200101 Stator 1

13 30195700302 Housing 1

14 30204400101 Brush holder 2

15 36209900101 Carbon brush 2

16 34730200201 Tapping screw\ST4x75C 2

17 34740300201 Pan head screw\M3x8 2

18 23824500101 Armature 1

19 37400100103 Capacitor\0.33μF 1

20 30213300101 Baffle 1

21 32024500101 Bearing bush 1

22 35400202001 Ball bearing\608.2Z 1

23 33499400201 Guide plate 2

24 33490000201 Spindle lock 1

25 35223400101 Spring 1

26 33810800201 Upper guard 1

27 33491100101 Plate 1

28 34751700101 Spring pin\φ6x36 1

29 32008900101 Rubber bumper 1

30 34737400201 Screw\M5x25 1

31 32604900101 Friction bearing\φ9xφ15x6.7 1

32 34714000101 Circlip for shaft\φ15 2

33 34400500201 Key\4x5x13

34 33239000101 Output shaft 1

35 33014100101 Gear 1

36 34713100101 Circlip for hole\φ28 1

37 35400100501 Ball bearing\6001.2RS 2

38 33800500101 Bearing holder 1

39 34791000101 Washer\φ5 2

40 34736000301 Countersunk head screw\M5x12 2

41 33490500302 Lower guard 1

42 34751900101 Circlip for shaft\φ34 1

43 37100209401 Cord 1

44 35223500101 Tension spring 1

45 32855800101 Inner flange 1

46 11045200601 Saw blade\φ190xφ20x24T 1

47 32846200101 Outer flange 1

48 34704400101 Hex. flange bolt\AM8x18 1

49 34734000401 Pan head screw\M4x8 2

50 32847800101 Orientation ring 1

51 34742300201 Locking screw\ A3 1

HKS15-65
