English | 13

Bosch Power Tools 1 609 92A 01H | (4.12.12)

Product Description and Specifications

Read all safety warnings and all instruc-

tions. Failure to follow the warnings and in-

structions may result in electric shock, fire

and/or serious injury.

While reading the operating instructions, unfold the graphics

page for the machine and leave it open.

Intended Use

The machine is designed for grinding and deburring metal us-

ing corundum grinding tools, as well as for working with sand-

ing wheels.

Product Features

The numbering of the product features refers to the illustra-

tion of the machine on the graphics page.

1 Collet

2 Clamping nut

3 Grinder spindle

4 Spindle collar

5 On/Off switch

6 Battery unlocking button*

7 Battery pack*

8 Handle (insulated gripping surface)

9 Button for charge-control indicator*

10 Battery charge-control indicator*

11 Open-end spanner on the grinder spindle*

12 Open-end spanner applied to clamping nut*

*Accessories shown or described are not part of the standard de-

livery scope of the product. A complete overview of accessories

can be found in our accessories program.

Noise/Vibration Information

Measured sound values determined according to EN 60745.

Typically the A-weighted noise levels of the product are:

Sound pressure level 77 dB(A); Sound power level 88 dB(A).

Uncertainty K=3 dB.

Wear hearing protection!

Vibration total values a

(triax vector sum) and Uncertainty K

determined according to EN 60745:

Surface grinding (with wheel diameter of 25 mm):

=3.5m/s

, K=1.5 m/s

The vibration emission level given in this information sheet has

been measured in accordance with a standardised test given in

EN 60745 and may be used to compare one tool with another.

It may be used for a preliminary assessment of exposure.

The declared vibration emission level represents the main ap-

plications of the tool. However if the tool is used for different

applications, with different accessories or poorly maintained,

the vibration emission may differ. This may significantly in-

crease the exposure level over the total working period.

An estimation of the level of exposure to vibration should also

take into account the times when the tool is switched off or

when it is running but not actually doing the job. This may signif-

icantly reduce the exposure level over the total working period.

Identify additional safety measures to protect the operator

from the effects of vibration such as: maintain the tool and the

accessories, keep hands warm, organise work patterns.

Technical Data

Declaration of Conformity

We declare under our sole responsibility that the product de-

scribed under “Technical Data” is in conformity with the fol-

lowing standards or standardization documents: EN 60745

according to the provisions of the directives 2011/65/EU,

2004/108/EC, 2006/42/EC.

Technical file (2006/42/EC) at:

Robert Bosch GmbH, PT/ETM9,

D-70745 Leinfelden-Echterdingen

Robert Bosch GmbH, Power Tools Division

D-70745 Leinfelden-Echterdingen

04.12.2012

Assembly

Battery Charging

 Use only the battery chargers listed on the accessories

page. Only these battery chargers are matched to the lith-

ium ion battery of your power tool.

Note: The battery is supplied partially charged. To ensure full

capacity of the battery, completely charge the battery in the

battery charger before using your power tool for the first time.

The Lithium-Ion battery can be charged at any time without

reducing its service life. Interrupting the charging procedure

does not damage the battery.

The Lithium-Ion battery is protected against deep discharging

by the “Electronic Cell Protection (ECP)”. When the battery is

empty, the machine is switched off by means of a protective

circuit: The inserted tool no longer rotates.

 Do not continue to press the On/Off switch after the

machine has been automatically switched off. The bat-

tery can be damaged.

Straight grinder GGS 18 V-LI

Article number

3 601 JB5 3..

Rated voltage

V= 18

Rated speed

min

-1

22000

Collet chuck diameter, max.

mm 8

Spanner size of

–clamping nut

–grinder spindle

Grinding tool diameter, max.

mm 50

Weight according to

EPTA-Procedure 01/2003 kg 1.8

Technical data determined with battery from delivery scope.

Dr. Egbert Schneider

Senior Vice President

Engineering

Helmut Heinzelmann

Head of Product Certification

PT/ETM9

OBJ_BUCH-1461-002.book Page 13 Tuesday, December 4, 2012 10:56 AM
