BOTTLE JACK

PASSPORT (USER MANUAL)

General safety instructions

The following precautions should be observed when working with the jack:

• Use it only for lifting loads.

• Do not exceed the estimated load capacity of the jack.

• Use safety devices when handling cargo.

• When lifting the vehicle, always put anti-rollback stops under the wheel to prevent the load from shifting.

• Use the jack only on a flat, hard surface to avoid dropping the load.

• During operation, the load must fall on the center of the jack's lifting platform.

• Do not violate the factory settings of the safety valve.

• Do not disassemble the jack. This may cause it to break or be damaged.

Product purpose

The hydraulic bottle jack is a manually operated device designed for lifting loads. Unlike other lifting mechanisms,

the jacks are located when lifting under the load, eliminating the need for auxiliary structures, ropes or chains, etc.

Working procedure

LIFTING CARGO

1. Close the exhaust valve tightly by inserting the handle with its narrow end into the valve seat and turning it

clockwise.

2. Place the jack under the vehicle in the appropriate place for lifting it (see the vehicle's operating instructions).

3. If necessary, turn the jack's extendable extension screw counterclockwise until it comes into contact with the

load.

4. Insert the handle into the slot and swing it to raise the load to the required height.

LOWERING THE LOAD

5. Remove the handle from the socket and insert the narrow end into the valve socket. Open the exhaust valve by

slowly turning the handle counterclockwise. The speed of lowering the load depends on the opening speed of

the exhaust valve. When opening the exhaust valve, do not make more than one complete turn.

6. When the load is fully lowered, remove the jack (if the extendable extension screw has been extended, rotate it

clockwise until it is lowered enough to allow the jack to be removed from under the vehicle).

Troubleshooting issues

Description of the problem Possible causes of the malfunction

The jack does not lift the rated load А B D E

The jack is lowered under the load А E

Oil seeps out from under the plug C

The pump is unstable in operation B D

The jack handle rises or falls under the load E

The jack does not rise to the maximum height B D

A. The exhaust valve may be loosely closed. Close the exhaust valve more tightly (but do not twist it).

B. The oil level in the jack may be low. Remove the oil tank plug and fill the tank with clean hydraulic oil

C. The tank may be overflowing. Remove the plug and drain the excess oil.

D. Air may have entered the system. Open the exhaust valve and swing the jack handle several times. Close the

exhaust valve and operate.
