*434723*
434723 English 23
Status Meaning
1 LED lights. Charge status: 10 % to 25 %
1 LED blinks, the power tool is ready for use. Charge status: < 10 %
1 LED blinks, the power tool is not ready for use. The battery has overheated or is completely dis-
charged.
4 LEDs blink, the power tool is not ready for use. The power tool is overloaded or has overheated.
Battery charge status cannot be displayed while the control switch is pressed and for up to 5 seconds
after releasing the control switch.
If the battery display LEDs blink, please observe the instructions given in the Troubleshooting section.
3.4 Fence
Use of the single arm fence allows precise cuts to be made along the edge of the workpiece, or strips of
even width to be cut.
The fence can be fitted on either side of the base plate.
3.5 Items supplied
Circular saw, saw blade, hex key, fence, vacuum cleaner hose connector, operating instructions.
Spare parts, consumables and accessories approved by Hilti for use with the product can be found at
your local Hilti Store or online at: www.hilti.group | USA: www.hilti.com
3.6 Accessories
Clamping flange, mounting flange, clamping screw.
4 Technical data
4.1 Circular saw
SCW 22-A
Rated voltage
21.6 V
Weight in accordance with EPTA procedure 01
4.1 kg
Specified blade diameter
160 mm … 165 mm
Blade disc thickness
0.5 mm … 1.5 mm
Kerf width
1.5 mm … 2 mm
Saw blade arbor size
20 mm
Rated speed under no load
4,000 /min
Maximum cutting depth
57 mm
Bevel cutting angle
0° … 50°
Operating temperature
−10 ℃ … 50 ℃
Storage temperature range (without battery)
−30 ℃ … 70 ℃
4.2 Battery
Battery operating voltage
21.6 V
Ambient temperature for operation
−17 ℃ … 60 ℃
Storage temperature
−20 ℃ … 40 ℃
Battery charging starting temperature
−10 ℃ … 45 ℃
4.3 Noise information and vibration values determined in accordance with EN 62841
The sound pressure and vibration values given in these instructions have been measured in accordance
with a standardized test and may be used to compare one power tool with another. They may be used
Printed: 24.05.2019 | Doc-Nr: PUB / 5070513 / 000 / 04
