*2111866*

2111866 English 23

4 Consumables

Only synthetic resin-bonded, fiber-reinforced discs with maximum Ø 125 mm which are approved for use at

a rotational speed of at least 11,000/min and a peripheral speed of 80 m/s may be used.

The maximum permissible grinding disc thickness is 6.4 mm and the maximum permissible cutting disc

thickness is 3 mm.

ATTENTION! When cutting or slitting with abrasive cutting discs always use the standard guard with

the additional front cover, or a fully enclosing dust hood.

Discs

Application Designation Material

Abrasive cutting disc Cutting, slitting ACD Metal

Diamond cutting disc Cutting, slitting DC-TP, DC-D (SPX,

SP, P)

Mineral

Abrasive grinding disc Rough grinding AGD, AFD, AND Metal

Diamond grinding disc Rough grinding DG-CW (SPX, SP,

Mineral

Diamond core bit Drilling in tiles DD-M14 Mineral

Suitability of discs for the equipment used

Item Equipment ACD AG-D AF-D AN-D DGCW DCD DD-M14

A Guard X X X X X X X

B Front cover (in combina-

tion with A)

X — — — — X —

C DG-EX 125/5" dust hood

for grinding

— — — — X — —

D DC-EX 125/5"C dust

hood for cutting (only in

conjunction with A)

— — — — — X —

E Side handle X X X X X X X

F DCBG 125 hoop handle

(optional for E)

X X X X X X X

G Clamping nut X X X X X X —

H Clamping flange X X X X X X —

Kwik lock (optional for G)

X X X X — X —

5 Technical data

AG 125A22

Rated voltage

21.6 V

Rated speed

9,500 /min

Maximum disc diameter

125 mm

Weight in accordance with EPTA Procedure 01 including B22⁄8.0 battery

3.3 kg

Drive spindle thread (arbor size)

M14

Spindle length

22 mm

5.1 Noise information and vibration values in accordance with EN 60745

The sound pressure and vibration values given in these instructions were measured in accordance with a

standardized test and can be used to compare one power tool with another. They can also be used for a

preliminary assessment of exposure. The data given represents the main applications of the power tool.

However, if the power tool is used for different applications, with different accessory tools, or is poorly

maintained, the data can vary. This can significantly increase exposure over the total working period. An

accurate estimation of exposure should also take into account the times when the tool is switched off, or

when it is running but not actually being used for a job. This can significantly reduce exposure over the

total working period. Identify additional safety measures to protect the operator from the effects of noise
