462706_m 29

Assembly

3.5 Appliance safety

■

Use the appliance only under the following

conditions:

■

The appliance is not soiled.

■

The appliance show no signs of damage.

■

All controls function properly.

■

Do not overload the device. It is intended for

light work in the private sector. Overload can

lead to damage to the appliance.

■

Never operate the appliance with worn or de-

fective parts. Always replace defective parts

with original spare parts from the manufactur-

er. If the appliance is operated with worn or

defective parts, guarantee claims against the

manufacturer are excluded.

■

Repair work is only allowed to be carried out

by expert workshops or our service centres.

3.6 Safety instructions relating to operation

■

Never leave the operational appliance unsu-

pervised.

■

Clean the appliance after every use.

■

Protect the appliance against unauthorised

access.

■

The appliance may only be operated by one

person.

■

Never move the appliance while the motor is

running.

■

Disconnect the appliance from the mains for:

■

Maintenance and cleaning work

■

Adjustment work

■

Transport

■

Interruptions in work

■

Faults

■

During the splitting process, do not reach into

the splitting area and do not touch the split-

ting wedge.

4 ASSEMBLY

WARNING! Danger if assembly is not

carried out completely! Operation of an incom-

pletely assembled appliance can result in serious

injury.

■

Only operate the appliance when it is fully as-

sembled.

■

Check that all safety and protective devices

are in place and functioning correctly before

switching on.

4.1 Assembly for LSH370/4 (06 – 15)

Assemble the appliance in the order of the fig-

ures (06) to (15).

4.2 Assembly for LSH520/5 (17 – 27)

Assemble the appliance in the order of the fig-

ures (17) to (27).

4.3 Installing protective cover (29 – 31)

Assemble the protective cover in the order of the

figures (29) to (31).

5 START-UP

5.1 Setting up and connecting log splitter

WARNING! Danger of injury if the log

splitter tips over. A tipping log splitter can result

in serious injury and material damage.

■

Set up the log splitter on firm and level

ground.

■

Do not place any material under the log split-

ter to change its height or to try to increase

its stability.

1. Set up the log splitter horizontally and se-

curely so that it cannot tip over.

2. Anchor the log splitter to the ground at the

appliance leg using two suitable screws

(16/1, 28/1) and possibly dowels to prevent it

from tipping over.

3. Lay the mains cable in such a way that it can-

not be kinked, crushed or damaged in any

other way.

4. Open vent screw (01/4, 02/4) by roughly 1 –

2 turns so that the air can escape that is dis-

placed during operation by the heated and

expanding oil.

5. Insert the plug of the mains cable into the

power socket.

Note:To disconnect the appliance from the

mains power supply, pull out the plug again.

5.2 Inspect safety and protective devices

Always check before starting work:

1. Check the proper anchoring of the log splitter

to the ground and correct, if necessary.

2. Inspect the protective cover for damage. Re-

pair the protective cover, if damaged.

3. Inspect two-hand operation: Procedure, see

see chapter 6.1 "Splitting a log (32 – 34)",

page30. While the log pusher is moving, re-

lease either ON button or control lever. The
