English | 15

When the charger level indicator (1) lights up red, the bat-

tery must be charged. Switch the machine off and charge the

battery.

Connect the machine to the charger (10) using the micro-

USB cable (9). Plug the charger (10) into the socket. The

charging process begins.

During the charging procedure, the handle of the machine

warms up. This is normal.

The charger level indicator (1) continuously lights up red

during the charging procedure. When the battery is com-

pletely charged, the charger level indicator (1) goes out.

Disconnect the battery charger from the mains supply when

charging process ends.

Observe the notes for disposal.

Mounting/Removing the Blade (see figures C)

Press the release button (12) and slide the cover (5) toward

the rear. Remove the cover (5) from the housing.

Tilt the blade (6)/(7) upward and then remove the blade

(6)/(7).

Align the recesses on the blade (6)/(7) against the holding

pins and then tilt the blade (6)/(7) downward.

Mount the cover (5) again and then slide it toward the front

until it engages.

Operation

u Make sure that the cover of the USB port (2) is shut dur-

ing operation. This prevents the penetration of dust.

u Do not use a damaged blade (e.g. cracks, etc.). Replace a

damaged blade immediately.

Switching On and Off (see figure D)

Press and hold the lock-off button (4) and actuate the On/

Off switch (3).

Release the lock-off button (4).

When actuating the On/Off switch (3), the LED continuously

lights up green.

Battery Charge Indicator

LED Capacity

LED continuously lights up green 33−100%

LED continuously lights up red

while On/Off switch is halfway

pressed.

0−33%

Cutting Shrubs (only Shrub Shear)

u Make sure that the product is switched off when removing

cut-off material or during maintenance. Unintentional

switching on may cause serious injury.

Before cutting check the hedge/shrub for foreign objects

e.g. wire fences.

Cut stems up to 8 mm in thickness. When cutting, move the

product steadily along the line of cut, so that stems are fed

directly into the cutter blades. The double edge of the cut-

ting blade enables cutting to either direction, or with a side

to side motion.

After use, mount the blade guard.

Recommended times

Cut hedges with deciduous leaves in June and October.

Cut evergreen hedges in April and August.

Cut conifer and other fast growing shrubs approx. every six

weeks from May onwards.

Cutting Edges (only Grass Shear)

Guide the product along the edge of the lawn. Prevent the

blade from coming into contact with paved paths, stones or

garden walls because this significantly reduces the lifetime

of the blade.

After use, mount the blade guard.

Troubleshooting

Problem Possible Cause Corrective Measure

Cutting time per bat-

tery charge too low

Battery close to end of service life. Contact Service Agent.

Charger level indicator

lights up red and the

product cannot be

switched on.

Battery temperature too high Ambient temperature too high Do not expose the

product to direct sunlight. Wait 10–15 minutes to

let battery cool down.

Maintenance and Service

Maintenance, Cleaning and Storage

u For safe and proper working, always keep the product

clean.

Do not place other objects on the garden product.

To ensure safe and efficient operation, always keep the

product and the ventilation slots clean.

Never spray the product with water.

Never immerse the product in water.

Store the product in a secure, dry place, out of the reach of

children.

Do not place other objects on the product.

Bosch Power Tools F 016 L94 120 | (03.12.2020)
