Careful planning is required for professional sealing. In addition,

depending on the individual dampness wear class and the type of foun‐

dation, a suitable thin bed sealing with a building regulations certificate

of suitability must be chosen.

Furthermore, the following factors should be taken into account:

n Drain or shower channel must be equipped with a special flange,

which has an adhesive surface and a width of at least 30 mm.

n For bridging the material change from drain to screed, either a suit‐

able sealing collar or sealing tape designed for overlapping with the

thin bed sealing over a width of at least 50 mm must be used.

n The screed must be laid at a minimum incline of 1–2 %.

n The installation must be carried out properly in acc. with the

mounting instructions and the manufacturer's information.

1-2%

1 2 43 5

8 67

Fig. 11: Construction diagram of the bonded seal - min. screed incline 1–2 %

1 Grate

2 Top piece with adhesive flange

3 Tile

4 Tile cement

5 Bonded sealing

6 Screed

7 sealing collar

8 adhesive

In connection with suitable drains, only approved bonded sealings with

proof of practicability in keeping with building law may be used. See

„Regulations from section: Sealing“ on page 7.

Information regarding the procedure can be found in the instructions for

use of the corresponding product.

Important note

Permitted bonded seals

Product information

Advantix Vario base unit, for Advantix Vario shower channel, can be cut to length continuously 17 from 50
