3.2.3 Mounting the closing caps on base unit

Screw the closing cap onto the profile straight.

When using a cordless screwdriver, make the last few turns by

hand.

Only tighten screws hand-tight!

The closing cap is properly mounted when the seal is pushed

together gently.

You must now calculate the height and align the shower channel

Chapter 3.2.5 „Determine height“ on page 30.

3.2.4 Pre-mounting extending parts

To start with, all short profile parts should pre-mounted. Then the pre-

mounted units are connected to the base unit.

NOTICE!

Risk of breakage when lifting

Do not lift or turn pre-mounted units on one side.

– In the case of L and U designs, lift the sides at the same

time.

M 3 Nm

≤

Handling

Advantix Vario base unit, for Advantix Vario shower channel, can be cut to length continuously 26 from 50
