2.2.3 Drainage capacity

For assembly with one drain

Accumulation

height

without sieve insert

Installation height

95 mm

without sieve insert

Installation height

165 mm

with sieve insert

Installation height

95 mm

with sieve insert

Installation height

165 mm

10 mm 0.45 l/s 0.75 l/s 0.4 l/s 0.7 l/s

20 mm 0.5 l/s 0.8 l/s 0.45 l/s 0.75 l/s

When two or three drains are combined using a collective connection

and a drainage capacity of > 0.8 l/s is expected, the dimensioning of the

drainpipe must be DN 70.

The drainage capacity of the

collective connection in DN 50

0.4–0.8 l/s (95–165 mm installation

height)

up to 0.8 l/s, see

„Regulations

from section: Drainage capacity“

on page 7

The drainage capacity of the

collector line in DN 70

two or three drains: 0.8–1.6 l/s

(95–165 mm installation height), see

„Regulations from section:

Drainage capacity“ on page 7

2.3 Product description

2.3.1 Installation variations

The length and shape of the Advantix Vario shower channel

can be variably adapted. Use the shower channel configu‐

rator to calculate the material required for any design avail‐

able: http://advantix-vario.viega.de/

The length of the shower channel can be adapted to suit:

n The base unit can be shortened to a length of 300 mm with milli‐

metre precision.

n The length of the shower channel can be extended up to 2800 mm

by installing accessory parts.

The shower channel can be altered in the following way using the fol‐

lowing accessories:

For mounting with collective connection (two or three drains)

Product information

Advantix Vario base unit, for Advantix Vario shower channel, can be cut to length continuously 9 from 50
