442240_a 43

Start-up

5.2

Charging the rechargeable battery (05, 06)

The rechargeable battery and the charging unit

are not included. The following li-ion recharge-

able batteries and charging units from AL-KO can

be used:

Product Designation Art. no.

Li-ion re-

chargeable

battery

B150 Li (B05-3640) 113280

Li-ion re-

chargeable

battery

B200 Li (B05-3650) 113524

Charging

unit

C05-4230 113281

The rechargeable battery is partially charged.

Fully charge the rechargeable battery before us-

ing it for the first time. The rechargeable battery

can be charged in any charge status. Interrupting

charging does not damage the rechargeable bat-

tery.

NOTE

For detailed information, heed the sepa-

rate operating instructions for the re-

chargeable battery and for the charging

unit.

CAUTION!

Danger of fire during

charging!

Due to heating of the char-

ger, there is a danger of

fire if it is placed on an in-

flammable surface and is

not adequately ventilated.

■

Always use the charger

on a non-inflammable

surface or in a non-com-

bustible environment.

■

If available: Keep the

ventilation slots free.

1. Insert the rechargeable battery (05/1) in the

charging unit (05/2) and plug the power plug

(05/3) into the power outlet. The charging

process begins and the LED for indicating the

operating status (05/4) flashes green.

2. Observe the LED (05/4). The charging pro-

cess takes approx. 1.5 – 2.0hours until fully

charged. The charging process ends auto-

matically when the rechargeable battery is

fully charged. The LED (05/4) then lights per-

manently green.

3. Disconnect the power plug (05/3) when the

LED (05/4) permanently lights green.

4. Press and hold the engaging button on the

bottom of the rechargeable battery.

5. Pull the rechargeable battery (05/1) out of the

charging unit (05/2).

Status displays on the charging unit (06)

The LED (06/1) on the charging unit indicates the

charge status of the rechargeable battery and the

operating condition of the charging unit. The sym-

bols (06/2) on the charging unit indicate these

states:

Symbol LED and charge status

LED lights green: The rechargeable

battery is fully charged.

LED flashes green: The recharge-

able battery is charging.

LED lights red: There is no recharge-

able battery in the charging unit.

LED flashes red: The rechargeable

battery is too hot and will therefore

not charge.

5.3 Determining the charge status of the

rechargeable battery (07)

There is a control panel with a pushbutton (07/1)

and LED charge status displays (07/2 to 07/5) on

the front of the rechargeable battery.

1. Press the pushbutton (07/1). The charge sta-

tus displays light according to the charge sta-

tus of the rechargeable battery.

2. To read the charge status, see section

"Charge status displays on the rechargeable

battery".
