Parts List

Item P/N Description Qty.

1 MPA1297 MOTORSPACERASSEMBLY 1

2 MPA0040 RETAININGRING 1

3 MPA0021 BEARING 1

4 MPB0017 REARENDPLATE 1

5 MPB0005 ROTOR 1

6 MPA0010 VANE 5

9 MPA0041 WOODRUFFKEY 1

11 MPA0042 O-RING 1

12 MPA0005 CYLINDERASSEMBLY 1

13 MPB0016 FRONTENDPLATE 1

14 MPA0019 BEARING 1

15 MPA1299 MOTORSHAFTASSEMBLY 1

16 MPA1295 MOTORSPACER 1

18 MPA0152 PLANETGEAR 3

19 MPA0224 NEEDLEBEARING 3

20 MPA0151 RINGGEAR 1

21 MPA0045 O-RING 1

22 MPB0060 SPINDLEHOUSING 1

23 MPA0456 PLANETARYSPINDLEASSEMBLY1/4-20UNC-2B 1

25 MPA0147 BEARING 1

26 MPA0213 SPACER 1

27 MPA0148 BEARING 1

28 MPA0110 RETAININGRING 1

29 MPA0117 RETAININGRING 1

30 MPA1711 THREADEDPLUG 2

31 MPB0401 RHNVHOUSING 1

32 MPA0032 MUFFLER 1

33 MPA1218 TOPHOUSINGSEAL 1

34 MPA1255 NVLOWERHOUSINGSEAL 1

35 MPA0510 INLETCAPTIVERING 1

36 MPA0509 O-RING 1

37 MPA0628 O-RING 1

38 MPA0776 MUFFLER 2

39 MPA0731 INLET/EXHAUSTENDCAPASSEMBLY 1

40 MPA0013 INLETBUSHINGASSEMBLY 1

41 MPA1398 SCREW,BLACK 4

42 MPA1865 SPACERRING 2

43 MPB0420 HANGER-BLACK 1

44 MPB0356 MOTORHOUSING 1

45 MPA0004 SPRINGPIN 1

46 MPA0015 VALVESLEEVE 1

47 MPA0655 VALVESTEMASSEMBLY 1

48 MPA2070 POLISHERTHROTTLELEVER 1

49 MPA0009 VALVESEAT 1

50 MPA0007 VALVE 1

51 MPA0014 VALVESPRING 1

52 MPA0730 AIRLINESEALASSEMBLY 1

53 MPA0500 EXHAUSTGASKET 1

54 MPB0182 NV/CVEXHAUSTNOZZLE 1

55 MPA0664 SCREW 3

56 MPA0517 EXHAUSTTUBING 1

57 MPA0516 TUBINGCLAMP 1

58 MPA0511 INLETTUBING 1

59 MPC0228 POLISHERSHROUD 1

60 MPA0145 13mmWRENCH 1

61 NA 1Back-UpPadsuppliedwitheachtool(typedeterminedbymodel) 1

62 MPB0402 LHNVHOUSING 1

63 MPA1430 SCREW,BLACK 7

64 MPA0043 O-RING 1

MPB0183 SPEEDCONTROL 1

MPA1939 FLUSHTWO-HANDSPEEDCONTROL OPT

66 MPA0039 RETAININGRING 1

67 MPA1981 SIDEHANDLE 1

68 MPA2541 FRONTBEARINGDUSTSHIELD 1
