English (Original instructions)
EN
DE ES IT FR PT NL RU FI SV NO DA PL CS SK SL HR HU RO BG EL AR TR HE LT LV ET
SPECIFICATIONS
Model 2200907
Voltage 40V
No load speed 3000 (±10%) min
-1
Blade speed 3000 (±10%) min
-1
Blade length 63 cm
Cutting capacity 27 mm
Measuered sound pressure
level
78.6 dB (A), k=3.0
Guaranteed sound power
level
100 dB (A)
Vibration level <2.5 m/s², k=1.5 m/s²
Weight without battery pack 2.70 kg
DESCRIPTION
See figure 1.
1. Blade
2. Guard
3. Front handle
4. Micro switch
5. Rotate release
6. Rear handle
7. Trigger switch
8. Lock-out button
9. Blade cover
ASSEMBLY
UNPACKING
This product requires no assembly.
Carefully remove the product and any accessories
from the box. Make sure that all items listed in the
packing list are included.
Inspect the product carefully to make sure no
breakage or damage occurred during shipping.
Do not discard the packing material until you have
carefully inspected and satisfactorily operated the
product.
PACKING LIST
Hedge trimmer
Operator's manual
OPERATION
For complete charging instructions, refer to the
Operator’s Manuals for your battery pack and charger
models.
NOTE: To avoid serious personal injury, always remove
the battery pack and keep hands clear of the lock-out
button when carrying or transporting the tool.
INSTALL BATTERY PACK
See figure 2.
Align the raised ribs on the battery pack with the
groove in the hedge trimmer’s battery port.
Press the battery pack down until it snaps into
position.
REMOVE BATTERY PACK
See figure 2.
Press the battery release button (10), the battery
pack will disengage from the battery port.
Grasp the battery pack and remove it from the
hedge trimmer.
CAUTION
When placing battery pack in your hedge trimmer, be
sure raised ribs on battery pack aligns with groove
in hedge trimmer and latch snaps in place properly.
Improper assembly of battery pack can cause
damage to internal components.
STARTING THE HEDGE TRIMMER
See figure 3.
Remove the blade cover.
Install the battery pack.
For added safety, there is a micro switch (4) in
the front handle. When operating, hold the hedge
trimmer with both hands, one hand to press the
lock-out button (8) and squeeze the trigger switch
(7), and the other hand to squeeze the micro switch
(4).
Release the lock-out button (8) and continue to
squeeze the trigger switch (7) and micro switch (4)
for extended operation.
STOPPING THE HEDGE TRIMMER
See figure 3.
Release the micro switch (4) and trigger switch (7)
to stop the hedge trimmer.
Upon release of the trigger switch (7), the lock-out
button (8) will be automatically reset to the lock
1
