12 Example applications

(The following images A1 to A6.3 are on a separate enclosed sheet).

A1.1 - A1.4 Stable and non-twisting mitred frame joint.

A2 Very stable block frame joint.

A3 Very stable and non-twisting wood joints in frame and chair construction.

A4.1 - A4.3 Stable, non-twisting and precisely ﬁ tting board joint (mitred).

A5.1 Stable and precisely ﬁ tting board joint (butted).

A5.2 Setting the Domino dowel jointer for board joint (butted), end face dowel hole.

A5.3 Setting the Domino dowel jointer with additional stop for board joint (butted).

A6.1 Stable and precisely ﬁ tting board joint (centred).

A6.2 Setting the Domino dowel jointer for board joint (centred).

A6.3 Setting the Domino dowel jointer for board joint (centred), end face dowel hole.

13 Fault correction

(The following images B1 to B6 are on a separate enclosed sheet).

Fault Cause Adjustment

B1 burns blunt jointer bit use sharp jointer bit

B2 expansion of dowel

hole

jointing depth excessive (greater

than 20 mm) with 5 mm jointing bit

reduce jointing depth

B3 dowel penetrates

workpiece

incorrect workpiece thickness

and/or jointing depth

adapt workpiece thickness and/

or jointing depth

B4 Tears at edge of dowel

hole

excessive feed rate reduce feed rate

B5 dowel hole not parallel

to workpiece edge

workpiece has shifted during

processing

secure workpiece properly

B6 dowel hole not at right

angles (90°) to work-

piece surface

a) deposits (e.g. chips) below the

base plate

b) angle guide not set exactly to 90°

c) worked on without additional

stop

a) remove deposits

b) set angle guide to 90° exactly

c) use additional stop

9a,

The position of the

dowel holes, which

were created with the

left and right stop latch,

does not exactly match

(different distance to

workpiece edge).

The midpoint between the two

stop latch is not exactly in the

midpoint of the swivel range of

the jointer bit.

Remove one of the stop latches

[9-1] (Fig. 9a). Attach one of

the accompanying stop latches

[9-2] to the dowel jointer (Fig.

9b).These stop latches are nar-

rower and allow you to make

more accurate adjustments.
