443223_b 33

Work instructions

Removing mulching insert (09)

1. Switch off the appliance and disconnect the

mains plug from the mains power supply.

2. Lift the baffle.

3. Release the locking mechanism (09/1) on the

mulching insert (09/a).

4. Pull out (09/b) the mulching insert (09/2).

6.7 Adjusting the handlebar to your body

size*

* depending on the model, see technical data.

6.7.1 Adjusting the handlebar – easy (10)

1. On both sides of the handlebar:

■

Loosen height adjustment screw (10/1).

■

Pull out screw (10/2).

2. Push upper brace (10/3) to the next hole in

lower brace (10/4) (10/a).

3. Tighten upper brace again in the reverse or-

der.

6.7.2 Adjusting the handlebar – comfort (11,

15)

1. Open quick-release levers (11/1) (11/a).

2. Rotate handlebar (11/2) around rotary/snap-

in joints (11/3) until the desired height is

reached (11/b).

3. Observe marking arrows (15/1).

4. Position plastic washers (15/2) and close the

quick-release levers.

6.8 Folding the handlebar in and out*

* depending on the model, see technical data.

After folding in the handlebar, the appliance can

be placed on its back to allow the mowing mech-

anism to be easily cleaned. This position also

saves space when storing the appliance.

CAUTION! Danger of crushing. Fingers or

other parts of the body can be crushed between

the loose parts of the handlebar.

■

Hold the loose parts of the handlebar tightly.

■

Do not hold any fingers or other parts of the

body between the loose parts.

6.8.1 Folding the handlebar in and out –

comfort (12, 15)

Folding in the handlebar

1. Release upper quick-release lever (12/1) and

fold the upper handlebar downwards.

2. Release lower quick-release lever (12/2) until

the entire handlebar can be folded forward in-

to the horizontal position.

3. Position plastic washers (15/2) and close all

quick-release levers.

Folding out the handlebar

Proceed in reverse order.

6.9 Starting and stopping the mower

mechanism (13, 14)*

* depending on the model, see technical data.

Start the mower mechanism on level ground and

not in long grass. The ground must be free of for-

eign bodies such as stones. Do not lift or tilt the

appliance to start it.

Starting the mower mechanism

1. Press start button (13/1, 14/1) and hold.

Pull operator presence control (13/2, 14/2) to-

wards the handlebar (13/3, 14/3) (13/a, 14/a).

The motor and mower mechanism are started.

3. Release the start button and keep holding the

operator presence control.

NOTE The operator presence control does

not lock in place. Hold it tight against the handle-

bar during the entire working period.

Stopping the mower mechanism

1. Release the operator presence control. It au-

tomatically returns to its starting position.

2. Wait for the mower mechanism to come to a

standstill.

CAUTION! Danger of cuts and lacera-

tions. Danger of lacerations when reaching into

the running mower mechanism.

■

Wait until the mower mechanism has

stopped.

■

Before all maintenance and care work:

Switch off the appliance and wait until the

mower mechanism has stopped. Disconnect

the mains plug from the mains power supply.

7 WORK INSTRUCTIONS

Observe the safety instructions!

NOTE Comply with the local regulations as

to when a lawnmower may be operated.

■

Watch out for objects in the grass and re-

move them from the working area.

■

Only mow when visibility is good.

■

Only mow with a sharp cutting blade.
